Catalog 23 - page 108

108
Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
www.orleansornamental.com
CLICK HERE FOR
THE TABLE OF CONTENTS
1/2: SQ.
SOLID
steel
DECORATIVE CIRCLES,OVALS & DRAPERY RINGS
Model Style Weight
NO. 1/2" Sq.Tubing
16 Gauge Rings
Size
3103...............3" O.D..................... .16 Lbs.
3102...............3 1/4" O.D.............. .20 Lbs.
3107...............3 1/2" O.D.............. .24 Lbs.
3104...............4" O.D..................... .31 Lbs.
3106...............4 1/2" O.D.............. .35 Lbs.
3105...............5" O.D..................... .51 Lbs.
3108...............6" O.D..................... .61 Lbs.
3109...............8" O.D..................... .57 Lbs.
3110...............10" O.D................... .70 Lbs.
Model Style Weight
NO. Oval
Cast Iron
Size
OS-3.........3"H.x 2 1/4" O.D.... .28 Lbs.
OS-4.........4"H.x 3 1/4" O.D.... .44 Lbs.
Model Inside Weight Material
NO. Diam. Rd.Steel
L69-4.............1"............... .04 Lbs.............3/16"
L79-3.............1 1/4"......... .04 Lbs.............3/16"
L81-1.............1 1/2........... .05 Lbs.............3/16"
L80-2.............2"............... .05 Lbs.............3/16"
L290-250.......2 1/2"......... .115 Lbs...........3/16"
L91-3.............3"............... .135 Lbs...........1/4"
L92-350.........3 1/2........... .145 Lbs...........1/4"
0Model Style Weight Circle
NO. Cast Iron Sides
Size Taper
833 3" O.D .57 Lbs. 1/2" x 5/8
9001 3 1/2" O.D .33 Lbs. 5/16" x 3/8"
9004 4 1/4" O.D .55 Lbs. 5/16" x 3/8"
835 5 1/4" O.D 1.10 Lbs. 1/2" x 5/8"
836 6" O.D 1 Lb. 1/2" x 5/8"
838 8" O.D (CLOSE OUT) 2 Lbs. 1/2" x 5/8"
circle
sides
taper
Model Style Weight
NO. 1/2" Round
Solid Rings
Size
W-4355-R......3" O.D.. ...... USA......... .44 Lbs.
W-4365-R......4" O.D.. ...... USA......... .62 Lbs.
W-4370-R......5" O.D . ...... USA......... .79 Lbs.
W-4375-R......6" O.D . ...... USA......... .96 Lbs.
3-RDS............3 1/2"O.D... IMPORT.. .60 LBS
4-RDS............4" O.D.. ...... IMPORT.. .62 LBS
Model Style Weight
NO. 1/2" Square
Solid Rings
Size
W-4382-S......3" O.D.............USA........ .58 Lbs.
W-4384-S......3 1/2" O.D.......USA........ .67 Lbs.
456SQ...........3 15/16" O.D...IMPORT.. .55 Lbs
W-4386-S......4" O.D.............USA........ .85 Lbs.
W-4388-S......5" O.D.............USA....... 1.04 Lbs.
W-4390-S......6" O.D.............USA....... 1.23 Lbs.
Model Style Weight
NO. 1/2" Rd.Tubing
16 Gauge Rings
Size
350T............. 3 1/2" O.D. IMPORT.. .30 LBS
378T............. 4" O.D. IMPORT.. .31 LBS
Model Style Weight
NO. 1/4" X 1/2"
Flat Bar
Rings
Size
452FB...............3 15/16" O.D............ .33 LBS
453FB...............4 5/16" O.D.............. .40 LBS
454FB...............4 15/16" O.D............ .45 LBS
Model Style Weight
NO. 1/4" X 1/2"
FLAT BAR
Curl Rings
Size
455FC............3 15/16" O.D........ .44 LBS
456FC............4 11/16" O.D......... .55 LBS
1/2: SQ.
TUBING
1/2: RD.
SOLID
3/16" RD. 1/4" RD.
1/2: RD.
TUBING
1/4" x 1/2"
SOLID
1/4" x 1/2"
SOLID
steel
steel
steel
steel
steel
steel
CAST
IRON
CAST
IRON
Drapery
Rings
Drapery
Rings
3/16" RD.
steel
Drapery
Rings
Model Inside Weight Material
NO. Diam. Rd.Steel
L69-4SI.........1"............... .04 Lbs.............3/16"
L79-3SI.........1 1/4"......... .04 Lbs.............3/16"
L81-1SI.........1 1/2"......... .05 Lbs.............3/16"
Model Inside Weight Material
NO. Diam. Rd.Steel
L79-NI...........1 1/4"......... .04 Lbs.............3/16"
NO INLET NO INLET
steel
3/16" RD.
Drapery
Rings
