MODEL................MANUAL................... HP MOTOR............CONTROL.........BATTERY.. .SOLAR......MAX.....................MAX
NO........................RELEASE................... MOTOR..................BOARD.............BACK UP... .READY.....LENGTH..............WEIGHT
E-200....................QUICK RELEASE..... 1/2HP......................DIAMOND........NONE..............NO.................20.’.................... 750 LBS
..............................LEVER....................... 120VAC...................................................................................................................................
E-200-1HP............QUICK RELEASE..... 1HP.........................DIAMOND........NONE..............NO.................24.’.................. 1000 LBS
..............................LEVER....................... 120VAC...................................................................................................................................
E-200-DM............QUICK RELEASE..... 1HP.........................DIAMOND........NONE..............NO.................20.’.................... 750 LBS
..............................LEVER....................... 120VAC...................................................................................................................................
eagle-200 swing gate operator
NOTE:
ALL OPERATORS WITH MODEL # THAT
ENDS WITH DM MEANS ITS HAS TWO
1/2 HP MOTORS 1 CLOSES THE GATE
& THE OTHER ONE OPENS THE GATE
NOTE:
ALL OPERATORS COME WITH A
LONG RANGE RECEIVER EG650
& A PHOTO EYE R EG650 & A PHOTO EYE
