painting process:
*M aterial is pre-galvanized *Gates and fence panels are thoroughly cleaned and degreased.
*Gates and fence panels are subject to an eco-friendly phosphate chemical solution treatment
*they are powder coated MATTE-BLACK
#WG469X (BLACK)
(WALK GATE)
46”H X 42 1/2”W
#WG709X (BLACK)
(WALK GATE)
70” H X 42 1/2”W
42 1/2” 66 1/2” 91 1/2”
#DG469X (BLACK)
(DRIVE GATE)
46”H X 66 1/2”W
#DG709X (BLACK)
(DRIVE GATE)
70”H X 66 1/2”W
#FP469X (BLACK)
(FENCE PANEL)
46”H X 91 1/2”W
#FP709X (BLACK)
(FENCE PANEL)
70”H X 91 1/2”W
#WG468832 (BLACK)
(WALK GATE)
46”H X 42 1/2”W
#WG708832 (BLACK)
(WALK GATE)
70”H X 42 1/2”W
#DG468832 (BLACK)
(DRIVE GATE)
46”H X 66 1/2”W
#DG708832 (BLACK)
(DRIVE GATE)
70”H X 66 1/2”W
#FP468832 (BLACK)
(FENCE PANEL)
46”H X 91 1/2”W
#FP708832 (BLACK)
(FENCE PANEL)
70”H X 91 1/2”W
46” OR 70” 46” OR 70”
46” OR 70”
42 1/2” 66 1/2” 91 1/2”
8832 SPEAR
11/2”x1/2”x1/8
PRE-FORMED
PUNCHED
CHANNEL
1 1/2”x11GA.
Sq.Tubing
&
1/2” x 16 ga.
Sq. Tubing
9-X SPEAR
1401 CAP
1401 CAP
11/2”x1/2”x1/8
PRE-FORMED
PUNCHED
CHANNEL
1 1/2”x11GA.
Sq.Tubing
&
1/2” x 16 ga.
Sq. Tubing
46” OR 70”
IMPORT FENCE,GATES & BRACKETS
# BRAC112
W-2”
L-2 1/4”
FITS OVER 1 1/2”
PRE-FORMED
CHANNEL
PICKET SPACING:
4” ON CENTER
3 1/2” BETWEEN EA.
PICKET
PICKET SPACING:
4” ON CENTER
3 1/2” BETWEEN EA.
PICKET
# BRAC112
W-2”
L-2 1/4”
CHECK OUT
MOUNTING
BRAKETS
BELOW
FOR
FENCE
PANELS
CHECK OUT
MOUNTING
BRAKETS
BELOW
FOR
FENCE
PANELS
FITS OVER 1 1/2”
PRE-FORMED
CHANNEL
PAINTED
MATTE-
BLACK
PAINTED
MATTE-
BLACK
5/16”
HOLE
5/16”
HOLE
