Regency Tuscany Railings All Painted With A Flat Black Primer
TUS-A1
Fits Level
Balcony Or
Landing
1/2"
SQUARE
IRON
1/2"
SQUARE
IRON
1/2"
SQUARE
IRON
1/2"
SQUARE
IRON
1/2"
SQUARE
IRON
TOP-VIEW
FLAT
TOP-VIEW
All Radius
From 28 inches to 20 ft.
TOP-VIEW
All Radius
From 28 inches to 20 ft.
TUS-B1
Fits Level
Balcony Or
Landing
TUS-C1
Fits Angels
20° to 36°
TUS-D1
Fits Angels
20° to 48°
TUS-E1
Fits Angels
37° to 48°
TUS-TERM
TOP-VIEW
FLAT
TOP-VIEW
FLAT
TOP-VIEW
FLAT
TOP-VIEW
FLAT
32 3/4"
42"
34 1/2"
42"
30 3/4"
42" 38"32" 38"32" 38"
34 1/2"
42"
32 3/4"
42"
30 3/4"
42" 38"32"
38"32"
38"32" 38"32"
30 3/4"
42"
32 3/4"
42"
34 1/2"
42"
TOP-VIEW
All Radius
From 30 inches to 20 ft.
TOP-VIEW
All Radius
From 30 inches to 20 ft.
TOP-VIEW
All Radius
From 30 inches to 20 ft.
TOP-VIEW
All Radius
From 28 inches to 20 ft.
TOP-VIEW
All Radius
From 28 inches to 20 ft.
TOP-VIEW
All Radius
From 30 inches to 20 ft.
TOP-VIEW
All Radius
From 30 inches to 20 ft.
TOP-VIEW
All Radius
From 30 inches to 20 ft.
TUS-A2 TUS-B2 TUS-C2 TUS-D2 TUS-E2
TUS-A3 TUS-B3 TUS-C3 TUS-D3 TUS-E3
TUS-TERM-L
Left Terminator
Right Side View
4 1/2"
Radius
4 1/2"
Radius
Note:All regency railing 1's are for straight & down rail.
Note:All regency railing 2's are for curved radius staircases looking up from the bottom. panels labeled as 2's always go to the right.
Note:All regency railing 3's are for curved radius staircases looking up from the bottom. panels labeled as 3's always go to the left
10" 10" 10" 10" 10"
10" 10" 10" 10" 10"
10" 10" 10" 10" 10"
1/2"
SQUARE
IRON
1/2"
SQUARE
IRON
1/2"
SQUARE
IRON
5/8"
SQUARE
IRON
1/2"
SQUARE
IRON
1/2"
SQUARE
IRON
1/2"
SQUARE
IRON
1/2"
SQUARE
IRON
1/2"
SQUARE
IRON
1/2"
SQUARE
IRON
TUS-TERM-R
Right Terminator
Left Side View
Tuscany
SCALE:1/2"-1'-0"
5/8"
SQUARE
IRON
5/8"
SQUARE
IRON
ALL REGENCY
RAILING IS SHIPPED
FOB
NEW ORLEANS,
LA.70122
OR
DALLAS TX..75207
ALL REGENCY
RAILING IS SHIPPED
FOB
NEW ORLEANS,
LA.70122
OR
DALLAS TX..75207
