Regency Railings All Painted With A Flat Black Primer
Regency
SCALE:1/2"-1'-0"
REG-A1
Fits Level
Balcony Or
Straight Rail
REG-B1
Fits All Angels
Up to 48°
Note:All regency railing 1's are for straight & down rail.
TOP-VIEW
All Radius
From 28 inches to 20 ft.
TOP-VIEW
All Radius
From 30 inches to 20 ft.
TOP-VIEW
All Radius
From 30 inches to 20 ft.
Note:All regency railing 3's are for curved radius staircases looking up from the bottom. panels labeled as 3's always go to the left
Note:All regency railing 2's are for curved radius staircases looking up from the bottom. panels labeled as 2's always go to the right.
REG-A2 REG-B2 REG-B2
REG-B1
Fits All Angels
Up to 48°
TOP-VIEW
FLAT
34 1/2"
42"
12"
3/8" X 1"
IRON
11 1/4" 11 1/4"
TOP-VIEW
FLAT
TOP-VIEW
FLAT
12" 11 1/4" 11 1/4"
12" 11 1/4" 11 1/4"
REG-A3 REG-B3 REG-B3
TOP-VIEW
All Radius
From 28 inches to 20 ft.
TOP-VIEW
All Radius
From 30 inches to 20 ft.
TOP-VIEW
All Radius
From 30 inches to 20 ft.
34 1/2"
42"
42"34 1/2" 42"29"
42"29"
42"29"
29"42"
29"42"
29"42"
1/2"
SQUARE
IRON
3"HIGH
1"
SQUARE
TUBEING
1"
SQUARE
TUBEING
1"
SQUARE
TUBEING
1/2"
SQUARE
IRON
4"HIGH
1/2"
SQUARE
IRON
4"HIGH
3/8" X 1"
IRON
1"
SQUARE
TUBEING
1/2"
SQUARE
IRON
4"HIGH
3/8" X 1"
IRON
3/8" X 1"
IRON
1"
SQUARE
TUBEING
1/2"
SQUARE
IRON
4"HIGH
3/8" X 1"
IRON
1/2"
SQUARE
IRON
3"HIGH
1"
SQUARE
TUBEING
3/8" X 1"
IRON
1"
SQUARE
TUBEING
1/2"
SQUARE
IRON
4"HIGH
3/8" X 1"
IRON
3/8" X 1"
IRON
1"
SQUARE
TUBEING
1/2"
SQUARE
IRON
4"HIGH
1"
SQUARE
TUBEING
1/2"
SQUARE
IRON
3"HIGH
3/8" X 1"
IRON
ALL REGENCY
RAILING IS SHIPPED
FOB
NEW ORLEANS,
LA.70122
OR
DALLAS TX..75207
ALL REGENCY
RAILING IS SHIPPED
FOB
NEW ORLEANS,
LA.70122
OR
DALLAS TX..75207
