Catalog 23 - page 145

145
Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
www.orleansornamental.com
CLICK HERE FOR
THE TABLE OF CONTENTS
Regency Rebecca Railings All Painted With A Flat Black Primer
REB-A1
Fits Level
Balcony Or
Straight Rail
5/8"
ROUND
IRON
TOP-VIEW
FLAT
REB-B1
Fits Angels
23° to 39°
REB-C1
Fits Angels
40° to 52°
REB-TERM-L
Left Terminator
44"
36 1/2"
TOP-VIEW
All Radius
From 28 inches to 20 ft.
TOP-VIEW
All Radius
From 30 inches to 20 ft.
TOP-VIEW
All Radius
From 30 inches to 20 ft.
REB-TERM-R
Right Terminator
4 1/2"
Radius
4 1/2"
Radius
Note:All regency railing 1's are for straight & down rail.
Note:All regency railing 2's are for curved radius staircases looking up from the bottom. panels labeled as 2's always go to the right.
Note:All regency railing 3's are for curved radius staircases looking up from the bottom. panels labeled as 3's always go to the left
14 1/2"
Rebecca
SCALE:1/2"-1'-0"
REB-A2 REB-B2 REB-C2
REB-A3 REB-B3 REB-C3
TOP-VIEW
All Radius
From 28 inches to 20 ft.
TOP-VIEW
All Radius
From 30 inches to 20 ft.
TOP-VIEW
All Radius
From 30 inches to 20 ft.
TOP-VIEW
FLAT
TOP-VIEW
FLAT
14 1/2" 14 1/2"
14 1/2" 14 1/2" 14 1/2"
14 1/2" 14 1/2" 14 1/2"
44"
36 1/2"
44"
36 1/2"
51"42"29 3/4
51"42"29 3/4
59"42"29 3/4
59"42"29 3/4
51"42"29 3/4
59"42"29 3/4
48 1/2"37 3/4"
37 3/4"48 1/2"
14 1/2"
14 1/2"
5/8"
ROUND
IRON
5/8"
ROUND
IRON
5/8"
ROUND
IRON 5/8"
ROUND
IRON
5/8"
ROUND
IRON
5/8"
ROUND
IRON 5/8"
ROUND
IRON
5/8"
ROUND
IRON
1/2"
ROUND
IRON
1/2"
ROUND
IRON
1/2"
ROUND
IRON
1/2"
ROUND
IRON
1/2"
ROUND
IRON
1/2"
ROUND
IRON
1/2"
ROUND
IRON
1/2"
ROUND
IRON
1/2"
ROUND
IRON
3/4"
ROUND
IRON
1"
ROUND
TUBEING
1"
ROUND
TUBEING
3/4"
ROUND
IRON
ALL REGENCY
RAILING IS SHIPPED
FOB
NEW ORLEANS,
LA.70122
OR
DALLAS TX..75207
ALL REGENCY
RAILING IS SHIPPED
FOB
NEW ORLEANS,
LA.70122
OR
DALLAS TX..75207
