Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
POST WEIGHT MODEL
SIZE EACH NUMBER
1”SQ. .04 LBS # W-5150-PC
1 1/4”SQ. .07 LBS # W-5162-PC
1 1/2”SQ. .09 LBS # W-5156-PC
2”SQ. .11 LBS # W-5100-PC
2 1/2”SQ. .20 LBS # W-5104-PC
3” SQ. .28 LBS # W-5106-PC
3 1/2”SQ. .36 LBS # W-5112-PC
4” SQ. .44 LBS # W-5120-PC
5” SQ. .50 LBS # W-5147-PC
6” SQ. .50 LBS # W-5149-PC
NEWELL WEIGHT MODEL
POST EACH NUMBER
SIZE
1”SQ. .10 LBS # W-3206-EC
1 1/4”SQ. .16 LBS # W-3207-EC
1 1/2”SQ. .22 LBS # W-3204-EC
2”SQ. .43 LBS # W-3202-EC
POST WEIGHT MODEL
SIZE EACH NUMBER
1”SQ. .03 LBS # 30-S
1 1/4”SQ. .04 LBS # 35-S
1 1/2”SQ. .04 LBS # 40-S
2”SQ. .07 LBS # 45-S
2 1/2”SQ. .17 LBS # 50-S
3” SQ. .26 LBS # 55-S
4” SQ. .33 LBS # 60-S
5” SQ. .45 LBS # 65-S
6” SQ. .66 LBS # 70-S
8” SQ. .67 LBS # 80-S
NOTE:Pressed steel caps has
radius corners,square post must
be rounded to fit
Pressed imported steel end caps
SQUARE TUBING DRIVE-ON CAP
FITS .73 & .083 WALL
PLASTIC RIBBED STYLE
DRIVE IN CAPS
(BLACK)
FITS INSIDE
14 TO 18 GAUGE
SQUARE TUBING
MODEL
# 7155
1/2”
MODEL
# 7165
5/8”
MODEL
# 7175
3/4”
MODEL
# 7100
1”
MODEL
# 7120
1 1/4”
MODEL
# 7130
1 1/2”
MODEL
# 7140
2”
MODEL
# 7150
1” x 2”
MODEL
# 7160
3”
NOTE:Pressed steel caps has
radius corners,square post must
be rounded to fit
USA
Pressed U.S.A steel end caps
DECORATIVE CAPS & PLUGS
TUBEING THICKNESS MODEL
SIZE NUMBER
1”SQ. 1/8" # W-3206-1
1 1/4”SQ. 1/8" # W-3207-1
1 1/2”SQ. 1/8" # W-3220-D
2”SQ. 1/8" # W-3221-D
4”SQ. 1/4" # W-D480
FLUSH SQUARE TUBING
WELD-ON STEEL CAPS
USA
MODEL
# 8100R
1/2”
MODEL
# 8101R
5/8”
MODEL
# 8102R
3/4”
MODEL
# 8103R
1”
MODEL
# 8104R
1 1/4”
MODEL
# 8105R
1 1/2”
MODEL
# 8106R
2”
MODEL
# 8107R
3”
PLASTIC RIBBED STYLE
DRIVE IN CAPS
(BLACK)
FITS INSIDE
14 TO 20 GAUGE
ROUND TUBING
PLASTIC RIBBED STYLE
DRIVE IN CAPS
(BLACK)
FITS INSIDE
14 TO 20 GAUGE
ROUND TUBING
steel
steel
RECT.
CHAMBER SHORT LEG
INSERT IN TUBING
THEN DRIVE ON
