88
Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
"L
awler
photographic
images
&
other
pertinent
information are
copyrighted
2008
by
L
awler
F
oundry
C
orporation
"
"L
awler
photographic
images
&
other
pertinent
information are
copyrighted
2008
by
L
awler
F
oundry
C
orporation
"
(1 LB)
cast iron
# 9506
H-1 3/4”
W-2 7/8”
(6.25 LBS)
cast iron
# 8607
H- 2 1/2”
W-7 1/8
(.99 LB)
cast iron
# 9540
H-1 1/2”
W-3 1/4”
(1.50 LB)
cast iron
# 9550
H-2”
W-3 3/4”
fits
over
1 1/4" sq.
(.68 LBS)
cast iron
# RR
H-1 1/4”
W-3 7/8
(1.50 LBS)
cast iron
# HH
H- 2”
W-3 3/4"
(2.25 LBS)
cast iron
# KK-2
H- 1”
W5”
fits
over
1 1/4" sq.
fits
over
1 1/4" sq.
fits
over
1 1/2" sq.
fits
over
1 1/2" sq.
fits
over
2" sq.
fits
over
2 1/2" sq.
(.50 LBS)
steel
# QC-9A01
W-2"
(.75 LBS)
steel
# QC-9A02
W-3"
fits
over
9/16" sq.
fits
over
1" sq.
(.76 LBS)
cast iron
# LSH-1
H- 1 7/8”
W-3 3/8
(.80 LBS)
cast iron
# LSH-114
H- 1 7/8”
W-3 1/2"
(.84 LBS)
cast iron
# LSH-112
H- 2”
W-3 5/8"
(1.36 LBS)
cast iron
# LSH-2
H- 2”
W-4 5/8"
fits
over
1" sq. &
3" Base
Plate
fits
over
1 1/4" sq.
3" Base
Plate
fits
over
1 1/2" sq.
3" Base
Plate
fits
over
2" sq.
4" Base
Plate
DECORATIVE SHOES,FLANGES,ADJUSTA-JAX, & COVER PLATES
fits
over
1" sq.
shoe slides
down to
anchor plate
1"SQ. NOT
INCLUDED
(.24 LBS)
STEEL
#913 (PLATE)
L-3 5/8”
W-1 7/8”
(.72 LBS)
cast iron
# 910 (SHOE)
H- 1 1/2”
W-4”
*ADJUSTA-JAX
*FITS 1”SQ.TUBE.
16 GAUGE
*ADJUSTABLE
TOLERANCE UP
TO 1 1/2”.
*PLACE LUG
INTO TUBEING
WITH BOLT &
SCREWALL
THE WAY UP,
AS YOU
UNSCREW
BOLT CONE
POINT TIES
INTO FLOOR
FOR A SECURE
HOLD
*COVER WITH
DD SHOE
*LUG IS 1”
SQUARE AT
BOTTOM &
PLUGS 1/2” IN
1”SQ.TUBEING
16 GAUGE
(.26 LBS)
cast & steel bolt
#1-AJ
ADJUSTA-JAX
fits
inside
1" sq.tube
(1.90 LBS)
STEEL
# L6054
H- 3 7/8”
W-3 7/8”
Base Plate
(No Holes)
Close-Out
(Non Refundable)
