82
Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
(.858 LBS)
# W-1930-FHB
PRESSED STEEL
1/4" THICK
FLAT TOP
EXT 2 1/2”
(.775 LBS)
# W-1930-RHB
PRESSED STEEL
1/4" THICK
ROUND TOP
EXT 2 1/2”
(.766 LBS)
# W-1938-RHB
PRESSED STEEL
1/4" THICK
ROUND TOP
EXT 3”
(.30 LBS)
# 3-RS
PRESSED STEEL
12 GAUGE
ROUND TOP
H-3 1/2"
W-2 3/4
EXT.2 5/8"
(.50 LBS)
# 7007
PRESSED STEEL
1/8" THICK
FLAT TOP
H-3 7/8"
W-2 5/8"
EXT 3”
(.55 LBS)
# W-1980-ST
PRESSED STEEL
1/4" THICK
FLAT TOP
EXT 2 1/4”
(.30 LBS)
# 3-FS
PRESSED STEEL
12 GAUGE
FLAT TOP
H-3 1/4"
W-2 3/4
EXT.2 5/8"
1"
2 1/4"
7/16"
HOLE
3.40"
(.88 LBS)
# W-1938-FHB
PRESSED STEEL
1/4" THICK
FLAT TOP
EXT 3”
2 5/8"
3"
2 5/8"
(1 LB)
steel
1/4" THICK
# QC-33
3" DIAM.
EXT.3 1/4"
DECORATIVE HANDRAIL BRACKETS,SNAP ON COVER,H-ADAPTER
(.50 LBS)
# 300RB
PRESSED STEEL
1/8" THICK
ROUND TOP
H-3 7/8"
W-2 5/8"
EXT 3”
3"
(.75 LBS)
# W-1978-R
PRESSED STEEL
1/4" THICK
ROUND TOP
EXT 3”
(.75 LBS)
# W-1978-F
PRESSED STEEL
1/4" THICK
FLAT TOP
EXT 3”
(.862 LBS)
# W-1929-FR
PRESSED STEEL
1/4" THICK
FITS RD. OR FLAT
EXT 3 1/4”
(.148 LBS)
# W-1960-SC
STEEL
SNAP -ON COVER
(.40 LBS)
# W-3482-F
PRESSED STEEL
1/4" THICK
FITS RD. OR FLAT
EXT 3"
3"
1 3/4"
3/8"
HOLE
1/4"
HOLEs
3"
1 3/4"
3/8"
HOLE
1/4"
HOLEs
H-ADAPTER
MODEL WEIGHT PIPE
NO. SIZE
W-3535-HA.... .080.......... 1 1/4"
W-3540-HA.... .097.......... 1 1/2"
W-1902-HA.... .150.......... 2"
EXAMPLE
SNAP-ON COVER
For concealed mounting of single hole Formed
Brackets can be use with model # W-1930-RHB,
W-1930-FHB,W-1938-RHB,W-1938-FHB,
W-3482-F, & W-1929-FR
IMPORT
IMPORT
IMPORT
USA
USA
USA
USA
USA
USA
USA
USA
USA
(.30 LBS)
# 212RB
PRESSED STEEL
1/8" THICK
ROUND TOP
H-4 1/2"
W-2 3/4
EXT.2 5/8"
(.30 LBS)
# 212FS
PRESSED STEEL
1/8" THICK
FLAT TOP
H-4 1/2"
W-2 3/4
EXT.2 5/8"
2 5/8"
2 5/8"
IMPORT
IMPORT
USA
USA
2 1/2”
2 1/2”
7/16”
1 3/4”
3”
1”
