(.53 LBS)
# 654
H- 3 3/4”
W-2 1/4”
(.64 LB)
TERMINAL
# 7053
H-9/16"
W-2 1/8"
L-3 9/16"
(.82 LB)
ANGLE
# 7051
H-5/8"
W-3 5/8"
L-3 5/8"
(.84 LB)
JOINING
# 7052
H-5/8"
W-2 1/8"
L-5 1/8"
(.14 LBS)
CORNER CAP
# 7055
H-3/4"
W-1 5/8"
L-1 5/8"
(24 LBS)
# MCR
H-1/2
W-1 3/4”
L- 20'
(.77 LBS)
PITCH
# 6-LT
H-4 1/2"
W-1 3/4”
L-4 3/8"
(.66 LBS)
STRAIGHT
# 5-LT
H-5"
W-1 3/4”
L-3 3/16"
(.99 LBS)
PITCH
# 6-XL
H-5 1/4"
W-1 3/4”
L-5 1/2"
(1.75 LBS)
# 4-X
H-2 1/2
W-1 5/8”
L-4 1/2”
(1.4 LBS)
STRAIGHT
# 5-XL
H-4 1/4"
W-1 3/4”
L-4 11/16"
(2 LBS)
VOLUTE
# 4-RE
H-4"
W-1 3/4”
L-4 1/4
(4 LBS)
LEFT (CAST)
# 400-L
H-11 1/2"
W-9 3/4"
(2.50 LBS)
LEFT (CAST)
# 401-L
H-11 1/2"
W-9 1/2"
(1.1 LBS)
LEFT(CAST)
# 1-CL-L
H-6 1/2"
W-6 1/4"
(2 LBS)
LEFT(CAST)
# 1-LS-L
H-6 1/2"
W-7"
(4 LBS)
RIGHT(CAST)
# 400-R
H-11 1/2"
W-9 3/4"
(2.50 LBS)
RIGHT(CAST)
# 401-R
H-11 1/2"
W-9 1/2"
(1.1 LBS)
RIGHT(CAST)
# 1-CL-R
H-6 1/2"
W-6 1/4
(2.25 LBS)
LEFT (DUCTILE)
# 401-HTD-L
H-11 1/2"
W-9 1/2"
(4 LBS)
LEFT (DUCTILE)
# 400-HTD-L
H-11 1/2"
W-9 3/4"
(4 LBS)
RIGHT (DUCTILE)
# 400-HTD-R
H-11 1/2"
W-9 3/4"
(2.25 LBS)
RIGHT (DUCTILE)
# 401-HTD-R
H-11 1/2"
W-9 1/2"
HEAT TREATED DUCTILE IRON
WILL NOT WITHSTAND MORE THAN
A 30 DEGREE COLD BEND
20'
laterals
laterals
laterals
CHANNELS
CHANNELS
CHANNELS
(ITEMS ON THIS PAGE CAN BE USED WITH THE #MCR & QC-MCR (MOLDED COVER RAIL
)
Steel: grooved to
fit 1/2" or 1' wide
material
(2 LBS)
RIGHT(CAST)
# 1-LS-R
H-6 1/2"
W-7"
DECORATIVE MOLDED COVER HANDRAIL IN STEEL & FITTINGS IN CAST IRON & DUCTILE
NOTE:WHEN ORDERING
LATERALS & CHANNELS
CHECK OUT THE
DESCRIPTION
ON
OPPOSITE PAGE
FITS MCR
(.95 LBS)
(MALLEABLE)
# OF-8XL
W-1 3/4"
(.50 LBS)
(MALLEABLE)
# OF-7CL
W-1"
1/2” LIP
90 DEGREE
90 DEGREE
