89
Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
POST FLANGE HEIGHT WEIGHT MATERIAL MODEL
SIZE SIZE SIZE EACH SIZE NUMBER
3/4” SQ. 3 3/4” SQ. 7/8” .55 LBS 10 GAUGE # W-8041-3F
1” SQ. 3 3/4” SQ. 7/8” .54 LBS 10 GAUGE # W-8041-F
1 1/4” SQ. 3 3/4” SQ. 7/8” .50 LBS 10 GAUGE # W-8045-F
1 1/2” SQ. 3 3/4” SQ. 7/8” .50 LBS 10 GAUGE # W-8047-F
2” SQ. 5” SQ. 1” 1.20 LBS 7 GAUGE # W-8051-F
2 1/2” SQ. 5” SQ. 1” 1.00 LBS 7 GAUGE # W-8049-F
POST FLANGE HEIGHT WEIGHT MATERIAL MODEL
SIZE SIZE SIZE EACH SIZE NUMBER
3 /4” SQ. 3” SQ. 1/2” .46 LBS 10 GAUGE # 8702
1” SQ. 3” SQ. 1/2” .42 LBS 16 GAUGE # 8709
1 1/4” SQ. 3” SQ. 1/2” .38 LBS 10 GAUGE # 8716
1 1/2” SQ. 3 3/4” SQ. 1/2” .57 LBS 10 GAUGE # 8723
2” SQ. 3 3/4” SQ. 1/2” .56 LBS 10 GAUGE # 8730
2 1/2”SQ. 5 3/16” SQ. 1” .59 LBS 16 GAUGE # 88058
FLANGE HOLE WEIGHT MATERIAL MODEL
SIZE SIZE EACH SIZE NUMBER
3” SQ. 3/8” .35 LBS 3/16” # 333
4” SQ. 3/8” .70 LBS 3/16” # 444
5” SQ. 3/8” 1.63 LBS 1/4” # 555
6” SQ. 3/8” 2.40 LBS 1/4” # 666-FP
8” SQ. 3/8” 4.00 LBS 1/4” # 888-FP
10” SQ. 1/2” 9.62 LBS 5/16” # 10-FP
POST FLANGE HEIGHT WEIGHT MATERIAL MODEL
SIZE SIZE SIZE EACH SIZE NUMBER
3/4” SQ. 2” SQ. 7/16” .14 LBS 10 GAUGE # W-8077-CP
1” SQ. 2” SQ. 3/8” .14 LBS 10 GAUGE # W-8079-CP
1 1/4” SQ. 3” SQ. 5/8” .38 LBS 10 GAUGE # W-8081-CP
1 1/2” SQ. 3” SQ. 5/8” .30 LBS 10 GAUGE # W-8083-CP
2”SQ. 4” SQ. 13/16" .70 LBS 7 GAUGE # W-8085-CP
1" x 2" RECT. 4” SQ. 7/8" .96 LBS 7 GAUGE # W-8091-CP
DECORATIVE FLANGES & COVER PLATES
POST
FLANGE WEIGHT MATERIAL HEIGHT MODEL
SIZE SIZE
EACH SIZE
SIZE NUMBER
1” SQ.
4” SQ.
.56 LBS 11 GAUGE 7/8"
# RSB-1
1 1/4” SQ. 4” SQ.
.54 LBS 11 GAUGE 7/8
# RSB-114
1 1/2” SQ. 4” SQ.
.52 LBS 11 GAUGE 7/8"
# RSB-112
2” SQ. 5 1/4” SQ. .50 LBS 11 GAUGE 7/8"
# RSB-2
SQUARE STEEL COVER PLATES
WIDE SQUARE STEEL FLANGES
SQUARE STEEL FLANGES
SQUARE STEEL PLATES
WIDE SQUARE STEEL FLANGES
USA
USA
USA
IMPORT
IMPORT
7/16"
HOLES
3/8"
HOLES
