81
Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
"L
awler
photographic
images
&
other
pertinent
information are
copyrighted
2008
by
L
awler
F
oundry
C
orporation
"
"L
awler
photographic
images
&
other
pertinent
information are
copyrighted
2008
by
L
awler
F
oundry
C
orporation
"
(2.75 LBS)
STRAIGHT
# 5-XLW
H-4 3/4"
W-2 1/4”
L-5"
(1.75 LBS)
BEVELED
# 6-XLW
H-4 1/2"
W-2 1/4”
L-5 3/8"
(40 LBS)
# MCRW
H-3/4"
W-2 1/4”
L-19'
(3.50 LBS)
LEFT(DUCTILE)
# 400-HTDW-L
H-10 3/4"
W-13"
(2 LBS)
VOLUTE
# 4-XW
H-2 11/16"
W-2 1/4”
L-4 3/4"
(3.50 LBS)
RIGHT(DUCTILE)
# 400-HTDW-R
H-10 3/4"
W-13"
(2.25 LBS)
LEFT(DUCTILE)
# 401-HTDW-L
H-9 3/4"
W-12"
(2.25 LBS)
RIGHT(DUCTILE)
# 401-HTDW-R
H-9 3/4"
W-12"
(20LBS)
# QC-MCRW
H-3/4"
W-2 1/4”
L-9' 10"
19' OR 9'10"
Ordering Laterals and Channels
(sold separately)
left lateral
left channel
(weld to lateral)
Right Channel
(flat side up)
ITEMS ON THIS PAGE CAN BE USED WITH THE
#MCRW & QC-MCRW (MOLDED COVER RAIL
)
EXAMPLES:
For Both sides of a staircase order
:
:
one set of laterals
:
two sets of channels
For ONE SIDE of a staircase order:
:
one laterals (either right or left hand)
:
one sets of channels
HEAT TREATED DUCTILE IRON
WILL NOT WITHSTAND MORE THAN
A 30 DEGREE COLD BEND
Steel: grooved to
fit 1 1/4" or 1 1/2'
wide material
WIDE
laterals
WIDE
CHANNELS
DECORATIVE MOLDED COVER HANDRAIL IN STEEL & FITTINGS IN CAST IRON & DUCTILE
(.90 LBS)
# 654-X
H- 4 3/8”
W-3”
FITS MCRW &
QC-MCRW
(.95 LBS)
(MALLEABLE)
# OF-10XLW
W-2 1/4"
(.50 LBS)
(MALLEABLE)
# OF-11CL
W-1 1/4"
1/2” LIP
90 DEGREE
90 DEGREE
