SQUARE PUZZLE--LOCK SPLIT FLANGE
THE ANSWER TO THOSE FORGOTTEN COVERS.THIS TWO-PIECE FLANGE
LOCKS TOGETHER TO APPEAR AS ONE.USE EPOXY FOR ATTACHMENT TO
SURFACE.
POST FLANGE HEIGHT WEIGHT MATERIAL MODEL
SIZE SIZE SIZE EACH SIZE NUMBER
1” SQ. 4” SQ. 7/8” .96 LBS 11 GA. # W-26430
1 1/4” SQ. 4” SQ. 7/8” .96 LBS 11 GA. . # W-26431
1 1/2” SQ. 4” SQ. 7/8” .96 LBS 11 GA. # W-26432
2” SQ. 4” SQ. 7/8” .96 LBS 11 GA. # W-26433
PLAIN FLANGE
POST FLANGE HEIGHT WEIGHT MATERIAL MODEL
SIZE SIZE SIZE EACH SIZE NUMBER
1” SQ. 3” SQ. 1 1/4” .60 LBS 10 GA. # W-8901
1 1/4” SQ. 3 3/4” SQ. 1 1/2” .65 LBS 10 GA. # W-8907
1 1/2” SQ. 3 3/4” SQ. 1 3/4” .84 LBS 10 GA. # W-8913
FLANGE WITH FOUR COUNTERSUNK HOLES
POST FLANGE HEIGHT WEIGHT MATERIAL MODEL
SIZE SIZE SIZE EACH SIZE NUMBER
1” SQ. 3” SQ. 1 1/4” .52 LBS 10 GA. # W-8902
1 1/4” SQ. 3 3/4” SQ. 1 1/2” .65 LBS 10 GA. # W-8908
1 1/2” SQ. 3 3/4” SQ. 1 3/4” .84 LBS 10 GA. # W-8914
FLANGE WITH SET SCREW & FOUR COUNTERSUNK HOLES
POST FLANGE HEIGHT WEIGHT MATERIAL MODEL
SIZE SIZE SIZE EACH SIZE NUMBER
1” SQ. 3” SQ. 1 1/4” .52 LBS 10 GA. # W-8905
1 1/4” SQ. 3 3/4” SQ. 1 1/2” .65 LBS 10 GA. # W-8911
1 1/2” SQ. 3 3/4” SQ. 1 3/4” .84 LBS 10 GA. # W-8917
HIDES BOLT HEAD
COVERS 4” SQUARE BASE
COVERS RUST RING
steel
steel
steel
steel
DECORATIVE FLANGES & COVER PLATES
USA
USA
USA
USA
