Catalog 23 - page 176

176
Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
www.orleansornamental.com
CLICK HERE FOR
THE TABLE OF CONTENTS
MARKS ORNAMENTAL IRON
KNOB/ROSE MORTISE LOCKSETS
*THRU-BOLTED,SOLID BRASS TRIMASSEMBLIES
*LOCK EASILY REVERSED
*SCREWLESS KNOBS
(LOCKSETS INCLUDES)
1.EXTERIOR & INTERIOR KNOB,ROSE,ASSEMBLY.
2.TWO CYLINDERS,5 PIN,MARKS “A”KEYWAY
ACCEPTS ARROW,KWIKSET & SEGAL 9
KEYED ALIKE IN SETS OF 12
3.CYLINDER COLLARS
4.INTEGRAL SPRING-LOADED SPINDLES.
BACKSET: 2 1/2”
5.REVERSIBLE MORTISE LOCK,1” BOLT,1/2” LATCH
6.STRIKE & MOUNTING SCREWS
TRIM FRONT
KNOBS 1 1/16” x 7 1/8”
MODEL # 22-WAC (POLISH BRASS)
(FITS LB-3,LB-4SB & LB-5SB LOCKBOXES)
1” WIDE LOCK BOX
(WITH SLAMBAR)
1” WIDE LOCK BOX
(NO SLAMBAR)
MODEL # LB-3
FITS 22-WAC & 21-WAC
MORTISE LOCK
7 3/8”
4 3/4”
MARKS ORNAMENTAL IRON
KNOB/ROSE MORTISE LOCKSETS
*THRU-BOLTED,SOLID BRASS TRIMASSEMBLIES
*LOCK EASILY REVERSED
*SCREWLESS KNOBS
(LOCKSETS INCLUDES)
1.EXTERIOR & INTERIOR KNOB,ROSE,ASSEMBLY.
2.TWO CYLINDERS,5 PIN,MARKS “A”KEYWAY
ACCEPTS ARROW,KWIKSET & SEGAL 9
KEYED ALIKE IN SETS OF 12
3.CYLINDER COLLARS
4.INTEGRAL SPRING-LOADED SPINDLES.
BACKSET: 2 1/2”
5.REVERSIBLE MORTISE LOCK,1” BOLT,1/2” LATCH
6.STRIKE & MOUNTING SCREWS
MODEL # LB-4SB
FITS 22-WAC & 21-WAC
MORTISE LOCK
MODEL # LB-5SB
FITS 22-WAC & 21-WAC
MORTISE LOCK
MODEL # 21-WAC (POLISH BRASS)
(FITS LB-3,LB-4SB & LB-5SB LOCKBOXES)
4 3/4”
7 3/4”
1” 4 3/4”
7 3/4”
1”
1” WIDE LOCK BOX
(WITH SLAMBAR)
(UNI-LOCK)
MARKS MORTISE LOCKSETS & STEEL LOCK BOXES
1"
MADE IN USA MADE IN USA
MODEL # 2750-C3
(POLISH BRASS)
MODEL # 2750-C26
(STAINLESS)
1.SOLID CAST BRASS
LEVER/PLATE ASSEMBLIES
2.THINLINE LOCK BODY.
3.DEADBOLT:DOUBLE CYL.
(SINGLE TURN) 1” THROW
MARKS THINLINE MORTISE
LOCKSETS OR DUMMY TRIM
(POLISH BRASS OR STAINLESS)
Fits The LB-28 Lockbox
MODEL # 2750-DT3
(POLISH BRASS)
MODEL # 2750-DT26
(STAINLESS)
1.SOLID CAST BRASS
LEVER/PLATE ASSEMBLIES
2.DUMMY TRIM
MODEL # LB-28
1”x2”x84”
(FITS 2650-C
THINLINE LOCKSET)
MODEL # 2600-SB
(FITS LB-28 LOCKBOX)
SLAMBAR
FOR THE LB-28
LOCKBOX
STEEL STEEL
8"Wx14"Hx1
3/4" D
MADE IN USA MADE IN USA
1.CONCEALED SCREWS
3.HARDENED STEEL
BOLTS 1/4”
4.1” BOLT THROWWITH
STEEL ROLL PIN
5.2 3/8” BACKSET
MARKS DOUBLE CYLINDER
DEADBOLT BY KEY
ON EITHER SIDE
(POLISH BRASS)
MODEL # 130-M
MARKS SINGLE CYLINDER
DEADBOLT BY KEY
ON ONE SIDE ONLY
(POLISH BRASS)
MODEL # 130-L
MARKS TURNPIECE
DEADBOLT BY
OUTSIDE KEY,
TURNPIECE WILL
RETRACT & LOCK BOLT
POLISH BRASS)
MODEL # 130-S
MARKS TUBULAR
DEADBOLTS
(MADE IN THE U.S.A.)
