Catalog 23 - page 178

178
Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
www.orleansornamental.com
CLICK HERE FOR
THE TABLE OF CONTENTS
LOCKEY DIGITAL LOCKSET,DEADBOLTS,LOCK BOXES,& CYLINDER SWING LOCK
Lockey Mechanical Code Deadbolt Lock
*Built in over sized knob for easy turning
*Operational one code panel on each side
*Satin Chome Finish *Deadbolt Function
*Double Combination available
*Adjustable Deadbolt (2 3/8"-2 3/4)backset
*Covers 2 1/8" hole
*Can be used with or without lock box
*Marine Grade Finish (Designed To Extend The
LifeTime Of The Finish When Exposed To The
Corrosive Elements Of Saltwater Environments.
MODEL # 2210 (SINGLE COMBINATION)
MODEL # 2210DC (DOUBLE COMBINATION)
LOCK BOX
SOLD SEPERATE
Lockey Mechanical Code Hookbolt Lock
Replaces Adams-Rite Lock
*1 1/8”Backset
*Five-Ply Laminated Steel Hook Bolt
With Concealed Hardened Steel Pin
*Built in over sized knob for easy turning
*Operational one code panel on each side
*Satin Chome Finish
*Can be used with or without lock box
* Marine Grade Finish (Designed To Extend The
LifeTime Of The Finish When Exposed To The
Corrosive Elements Of Saltwater Environments.
MODEL # 2950 (SINGLE COMBINATION)
MODEL # 2950DC (DOUBLE COMBINATION)
MODEL # K-G23 (STEEL)
MODEL # K-G23AL (ALUMINUM)
MODEL # GB950 (STEEL)
MODEL # GB950AL (ALUMINUM)
*Lockey Panic BARS
*ANSI/BHMAA156.3 Series Grade 1 Certified
*Complies with ANSI A117.AADA requirements
*UL/cul Listed
*Narrow Style 2 1/2”-Door Thickness:1 3/4”(Standard)
*Device Length:33” (36”Doors)
*Field-Sizable-Can be cut to 27”
*Latch Bolt:Stainless Steel Powder Metallurgy With 11/16” Throw
*Deadlocking Latch:Stainless Steel Powder Metallurgy With 9/16” Throw
*Weather Resistant
*Materials:Plated Steel or Stainless Steel with Zinc or Stainless Steel head cover
*Plated Steel (AL)
*Stainless Steel (SS)
MODEL
NO. Doors Size Material
PB-1100-AL..... 36"....... Plated Steel (AL)
PB-1100-SS...... 36”........ Stainless Steel
MODEL
NO. Panic Shield Size Color
PS-1124B............24".................Black
PS-1124S............24”.................Silver
*Lockey Panic Shields adjustable up to 52” wide with
Mounting Holes For LOCKEY PANIC BARS
Lock Box
F or Panic Bar
Fits Model
#285P
Lever H andle
Combination
Lock
KEY BOXES & CYLINDERS
MODEL
NO. COLOR
PSGB-200-B.... BLACK
PSGB-200-S..... SILVER
MODEL
NO. COLOR
PSGB5-B.......... BLACK
PSGB5-S.......... SILVER
MODEL
NO.
PS-CYL-KA
PS-CYL-KD
MODEL
NO.
PS-CYL-ICD
IC CORE
CYLINDERS
KEYEDALIKE OR
KEYED DIFFERENT
MODEL
NO. COLOR
PS-SB-B...... BLACK
PS-SB-S....... SILVER
*STRIKE BRACKET 1/4”STEELWITH
POWDER COATED FINISH
*ADJUSTABLE,FITS UPTO 3” POST
MODEL
NO. COLOR
PS-MAX-B. BLACK
PS-MAX-S.. SILVER
*MOUNTSABOVE PANIC BAR,
PREVENTING TAMPERING FROM
OUTSIDE OF GATE.
*16-GAUGE ELECTRO-GALVANIZED
STEEL
Lockey Mechanical Code Lock
*Keyless Panic Trim
*Lever Handle
*Satin Chome Finish
*Takes The Place Of A Keyed Cylinder
*Panic Bar Must Accept A Flat Tailpiece And
Have A Turn Radius Of 90 Degrees Or Less.
*Features Passage Function
*Reversible Handing
*Marine Grade Finish (Designed To Extend The LifeTime
Of The Finish When Exposed To The Corrosive Elements
Of Saltwater Environments.
MODEL #285P (SINGLE COMBINATION
Lock Box
F or Panic Bar
Fits Model #PS-CYL
(KEYED CYLINDERS)
single combination single combination
MODEL
NO. COLOR
PSGB-LHB......BLACK
PSGB-LHS......SILVER
Lock Box
F or Panic Bar
F its Model A bove
#PB-LHSR
Lever Handle
MODEL
NO. STYLE
PB-LHSR-KA ..STOREROOM
PB-LHSR-KD ..STOREROOM
SATIN
CHROME
STOREROOM HANDLE
STAYS LOCKED ALL THE TIME
FOR THE PANIC BAR
The 2835 Series Combination Lever Handle Lock with passage function has
grown increasingly popular with this lock being right or left handed,
mechanical and also available in single or double combination.This lock is
Teflon coated parts,marine grade,saltwater environment deadlocking spring
latch.it is most commonly used on gates and pool areas where a
combination is needed to enter and exit
Lockey Mechanical Code Lock
Lever Handle Mechanical Code Lock With
Passage Function.Available In Single Or Double Code Handle
Features:
*Teflon coated parts,marine grade,saltwater environment friendly
*Satin Chome Finish *Passage Function *Easy Installation*Weather
Resistant
*Operational one code panel on each side
*Easy Changeable Combination *To change the code the lock must be
taken off the door
*2 3/8" backset *Covers 2 1/8" hole *Can be used for left or right hand
doors
*Lifetime Guarantee On The Mechanics Specifications:
*Dimensions: 5 1/2"H x 1 5/8"W x 2 1/4"D *Ada Lever size: 4"Wx 1" H
*Total Coverage W/Trim: 6 1/2" x 2 1/2" W
*Can be used with or without lock box
MODEL # 2835MG
(SINGLE COMBINATION)
MODEL # K-G23
(Steel Lockbox Fits Lockey Combinations )
H-7 5/8 x 4 3/4"W x 1 3/4"D. ,14 Ga. x 2 3/8" Backset
MODEL # 2835DCMG
(DOUBLE COMBINATION)
LOCK BOX
SOLD SEPERATE
K-G23 (STEEL) OR
K-G23(ALUMINUM)
MODEL # K-G23AL
(Aluminum Lockbox Fits Lockey Combinations )
H-7 5/8 x 4 3/4"W x 1 3/4"D., 125 Alum. x 2 3/8" Backset
Teflon Coated Parts,Marine Grade,
SaltwaterEnvironment Friendly
The 3230 Series Combination Deadlocking Spring Latch is a Teflon
coated part,marine grade saltwater environment deadlocking spring
latch.it is most commonly used on gates and pool areas where a
combination is needed to enter and exit.
Lockey Mechanical Code Lock
Round Ribbed Knob Mechanical Code Lock With
Passage Function.Available In Single Or Double Code Handle
Features:
*Teflon coated parts,marine grade,saltwater environment friendly
*Built in over sized knob for easy turning *Locks automatically*
*Operational one code panel on each side
*Satin Chome Finish *Passage Function *Easy Installation *Weather Resistant
*Easy Changeable Combination *To change the code the lock must be taken off
the door
*2 3/8"backset *Covers 2 1/8" hole *Can be used for left or right hand doors
*Lifetime Guarantee On The Mechanics Specifications:
*Dimensions: 6 1/4"H x 1 3/4"W x 1 5/8"D *Ada Lever size: 4"Wx 1" H
*Total Coverage W/Trim: 7" x 2 1/2" x 1 5/8" D
**Can be used with or without lock box
MODEL # 3230MG
(SINGLE COMBINATION)
MODEL # 3230DCMG
(DOUBLE COMBINATION)
LOCK BOX
SOLD SEPERATE
K-G23 (STEEL) OR
K-G23(ALUMINUM)
Teflon Coated Parts,Marine Grade,
SaltwaterEnvironment Friendly
LOCK BOX
SOLD SEPERATE
K-G23 (STEEL) OR
K-G23(ALUMINUM)
