183
Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
LOCINOX HYBRID LOCK KITS FOR SWING GATES
MOUNTS TO METAL(100% Stainless Steel Mechanism
*Easy left or right changing of the self-latching bolt
*Key-operated self-latching bolt
*Adjustments of the latch bolt up to 3/4" continuous without removing
the lock
*Mechanism,hook,frontplate,latchbolt:Stainless Steel
*Stainless steel hook for night locking
*throw of the hook:1 1/4"
*Center-distance cylinder<=>handles=>3 5/8"
*Hook in combination with the keep provides a secure anchoring
*With coverplate for lockmechanism protection against dirt penetration
inside the posts
* Available with 2",2 1/2" and 3" cylinder
Note: Note: Special Order Cylinders are avaible in
Schlage,Kwikset only
HYBRID COMPLETE LOCKSET FOR METAL
MODEL
#
HWLB
WELDING BOX FOR HY6060WB
*Size:2 2/8 X1 9/16" X 8 5/8"
(5/64"thickness,14 gauge)
*Black steel for welding
MODEL
#
HLT
WELDING BOX FOR HY6060
*Welding profile for hybrid 6060
*Size:2 3/8 X1 9/16" X 78 3/4"
(1/16"thickness,16 gauge)
*Black steel for welding
*Fully prepared:facilitates the
preparation of your gates
MODEL
#
HKT
WELDING BOX FOR KEEP
*Welding profile for hybrid keep:shkm
*Size:2 3/8 X1 9/16" X 78 3/4"
(1/16"thickness,16 gauge)
*Black steel for welding
*Fully prepared:facilitates the
preparation of your gates
MODEL
#
H3020
Polyamide shield/cover
for hybrid lock,
black set of 2 pc
s.
MODEL
#
H3020A2
Stainless Steel/cover
shield for hybrid lock,
black set of 2 pc
s.
MODEL
#
SHKMQFAL
(keep for metal)
*Stainless steel keep for hybrid locks
*Adjustable for profiles 1 1/2< > 2 3/8"
*Mounting:innovative Quick-fix
*Anchoring plate for hook
MODEL
#
HWKB
WELDING BOX & KEEPER
FOR HYBRID
*Size:2 2/8 X1 9/16" X 8 5/8"
(5/64"thickness,14 gauge)
*Black steel for welding
*Frontplate in stainless steel
*Integrated gate-stop with
2 rubbers
MODEL
#
SE-HE
(ELECTRIC STRIKE)
Fail closed (Secure) Reversible for
Left or Right hinged gates,
2" Post minum
(When you lose power its stays close)
__________________
#
SE-HR
(ELECTRIC STRIKE)
Fail open (Secure) Reversible for
Left or Right hinged gates,
(When you lose power its stays open)
2" Post minum
MODEL
#
HLK60WB
(kit)includes:
HY6060WB(LOCK)
H3020(SH/COVERS)
3006I (LEVERS)
3012GSX(2"CYL)
SHKMQFAL(KEEP)
MODEL
#
HLB60WB
(kit)includes:
HY6060WB
H3020(SH/COVERS)
3006I (LEVERS)
3012GSX(2" CYL.)
HWLB(BOX)
HWKB(BOX&KEEP)
MODEL
# 3006I (STAINLESS)
(FITS 1 1/2'- 2" THICK)
3006IH (STAINLESS)
(FITS 2”- 3" THICK)
LOCINOX HYBRID LOCKS FOR SWING GATES
The electric strike
are for the hybrid
LOCKS
MODEL # T12VAC
Transformer
120VAC-12VAC,
40VA,Plug In Iype
MODEL # T12VDC
Transformer
120VAC-12VDC,
1A,Plug In Iype
transformer
for
the
electric
strike
CLOSE
OUT
CLOSE
OUT
MODEL
#
FORTYLOCK
KEEPER FOR
THE FORTYLOCK
MODEL
#
SFKI-QF40
• Lock mechanism with cover plate protects against dirt penetration
• Patented “Click-It” system makes tapping thread in the profile unnecessary
• Continuous adjustment of the latch bolt up to 3/8” without removing the lock
• Key-operated self-latching bolt
• Mechanism, hook, front plate, latch bolt: stainless steel
• Easy left or right hand changing of the self-latching bolt
• Stainless steel hook for night locking (dead bolt)
• Throw of the hook: 13/16”
• Center-distance cylinder <=> handles = 3-5/8”
• Compatible with Euro-profile cylinders
Mortise lock with 100% stainless steel mechanism. The stainless steel and adjustable
self-latching bolt combined with the right keep guarantee a strong and solid closed gate where
the gate cannot be pulled apart or forced open. The lock can be installed on metal, aluminum
and PVC gates. Thanks to the patented “Click-It” system, mounting the lock can be done in
a matter of seconds.
Replacement
Handles For
Hybrid
