Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
LOCINOX SINGLE SIDED MECHANICAL LOCKS FOR FREE EXIT SWING GATES
"
MECHANICAL FREE EXIT CODE LOCK FOR SWING GATES
(Note:All The Lockboxes Are 1 1/4" WIDE By Faceplate)
MODEL
NO. FRAME/THICKNESS COLOR
#LFPQ10XBL......1/2” to 1” Thick. .............
BLACK
#LFPQ10XSL.......1/2” to 1” Thick. .............
SILVER
#LFKQ30XBL......1-1/4” Thick. ...................
BLACK
#LFKQ30XSL .....1-1/4” Thick. ...................
SILVER
#LFKQ40XBL......1-1/2” to 2” Thick...........
BLACK
#LFKQ40XSL......1-1/2” to 2” Thick...........
SILVER
#LFKQ60XBL......2 1/2” to 3” Thick. ..........
BLACK
#LFKQ60XSL .....2 1/2” to 3” Thick. ..........
SILVER
MODEL #
IN COLOR BLACK COMES WITH
SILVER HANDLES & BLACK BOX
&
MODEL #
IN COLOR SILVER COMES WITH
THE SILVER HANDLES & SILVER BOX
LOCINOX LOCK FOR SWING GATES
MECHANICAL CODE LOCK-STAINLESS STEEL
*100% mechanical:no battery or electricity required
*Operational code panel adjusts to each side
*Easy and fast set-up or modification of the access codes
*With adjustable rollerbolt for easy closing
*Possibility of setting up 4 to 6 digit codes
*Extremely strong and user-friendly mechanism
*Automatic code reset after opening with the handle
*Anti-code detection with integrated security press plate
*Lockbox 1 1/4” X 3 3/4” Wide
*The latch bolt has 3/4” continuous adjustment to allow
perfect alignment of the locking mechanism
*The standard & security keepers require a 1 1/4 latch gap
Single Sided
Mechanical Code
Lock With a Latch
Note:LOCKS COMES WITH
A LEVER ON FRONT &
KNOB ON REAR & ALSO
THERE IS NO DEADBOLT
ON THE FREE EXIT
MECHANICAL CODE LOCK
ANCHORING SECURITY GATE STOP & KEEPER FOR SWING GATES
MODEL
NO. MIN.SIZE MAX SIZE COLOR MOU
NT
#
SHKLQFBL
........1-1/2"............>...................... BLACK..... QUICK-FIX
#
SHKLQFAL
........1-1/2"............>...................... ALUM...... QUICK-FIX
MODEL
NO
#6403
ROUND ADAPTOR PLATE
FOR SH KEEPERS
STANDARD GATE STOP & KEEPER FOR SWING GATES
MODEL
NO. MIN.SIZE MAX SIZE COLOR MOU
NT
#
SAKLQFBL
....... 1-1/2".............>........................BLACK.....QUICK-FIX
#
SAKLQFAL
....... 1-1/2".............>........................ALUM.......QUICK-FIX
STOP &
KEEPER
Gap Between
Post & Gate
Is 1 1/4"
MODEL
NO.
#
3018LA
ROUND ADAPTOR PLATE
FOR SA KEEPERS
R
ecommended
K
eeps
R
ecommended
K
eeps
Push-Set in SILVER
Exit shown installed with lock.
Lock is Not included.
(FITS INDUSTRAIL LOCK &
FREE EXIT MECHANICAL CODE
LOCK ONLY)
*The set is adaptable on all stainless
steel locinox locks with u-lockbox
*The push-set replaces the handles
*Facilitates the opening of the gate
MODEL NO.
# 3006PUSH (ALUMINUM)
*Optional Push Handle*
Model#3006push
avaible for the
free exit side see below
To upgrade the cylinders to Medeco &
Best sfic (small format interchangeable core)
will be done at the factory in
illinois which will include the
complete set with the new
cylinders. Example when ordering:
Order the model # of the lock &
& then
#3012BEST-V8
(U8Sl Lock Box,8e Housing,&
1 Const Core (Fits Lakq Style),
3 1/8”
NOTE:COMES IN SILVER
ONLY
