Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
LOCINOX LOCK FOR SWING GATES
ELECTRIC LOCK-STAINLESS STEEL
*Voltage:12 v ac/dc
*Current:O.3 amps
*Loss of power=>Lock will release the knobs (fail open)
*Blocking or releasing of the knobs
*Led-indication:blocked knobs
*Easy left or right changing of the self-latching bolt
*Throw of 1"in 1 turn of the key
*Key-operated
*Adjustment of the bolts up to 3/4" continuous without
removing the lockbox
*4-hole mounting with two hex socket head screws
*Center distance bolts: 2 3/8"
*Lockbox width:3 1/2"
MODEL # DVK-HD
Flex Conduit w/jct.
Boxes,17-1/2"L,Silver
MODEL # T12VAC
Transformer
120VAC-12VAC,
40VA,Plug In Iype
MODEL # T12VDC
Transformer
120VAC-12VDC,
1A,Plug In Iype
MODEL # T12VDC
Transformer
120VAC-12VDC,
1A,Plug In Iype
MODEL # 2005
Silicone Wire,2x0.75mm,
16'l,Weatherproof
LOCINOX LOCK FOR SWING GATES
ELECTRO MAGNETIC LOCK-STAINLESS STEEL
*Fast and easy fixing by means of 5 holes
*No welding required
*Same center-distance as the standard locinox keeps
*Aluminum coated design casing
*Fail open
*Easy & fast mounting:Quick-fix
MODEL # MAG2500BL
(600 LBS) minimal pulling force
*Voltage:12V/24V DC
*Current:360mA/12V OR 180mA/24V
MODEL # MAG5000BL
(1200 LBS) minimal pulling force
*Voltage:12V/24V DC
*Current:500mA/12V OR 250mA/24V
Magnetic lock for Pedestrian swing gates
(Includes Lock With Handles & Mounting Hardware)
MODEL
NO. Minimal Pulling Force COLOR
#MAG2500BL...........
600 LBS.......................................
BLACK
#MAG2500SL............
600 LBS.......................................
SILVER
#MAG5000BL...........
1200 LBS.....................................
BLACK
#MAG5000SL............
1200 LBS.....................................
SILVER
MODEL #
IN COLOR BLACK
COMES
WITH THE SILVER
HANDLES & BLACK
BOX
NOTE: NO FREE EXIT
HAS TO BE BUZZ IN &
BUZZ OUT
Gap Between Post &
Gate Is 3/4"
MODEL
# SE-E
(ELECTRIC STRIKE)
Fail closed (Secure) Reversible for Left
or Right hinged gates,2" Post minum
(when you lose power its stays close)
MODEL
# SE-R
(ELECTRIC STRIKE)
Fail open (SAFE) Reversible for Left
or Right hinged gates,2" Post minum
(when you lose power its stays open)
Gap Between Post &
Gate Is 1"
LOCINOX ELECTRIC & MAGNETIC LOCKS,STRIKES,ACCESSORIES FOR SWING GATES
Note:Requires a
12 Or 24 Volt DC
Transformer
Note:Requires a
12 Volt AC/ DC
Transformer
magnum on
post
in a
close
position
transformer
for
the
electric
locks
transformer
for
the magneticlocks
FRAME/THICKNESS
1 1/2"-2 1/2” SQUARE>>>
Note: Special Order Cylinders are avaible in Schlage,Kwikset,
Medeco & Best sfic (small format interchangeable core)
MODEL
NO. FRAME/THICKNESS COLOR
#LEKQ30UBL.............1-1/4"
Thick.............
........................BLACK
#LEKQ30USL .............1-1/4”
Thick..............
........................SILVER
#LEKQ40UBL.............1-1/2" to 2”
Thick.
........................BLACK
#LEKQ40USL..............1-1/2” to 2”
Thick.
........................SILVER
Fail open (SAFE)
(when you lose power its stays open)
Fail open (SAFE)
(when you lose power its stays open)
