193
Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
REP.HANDLES
(ZAMAC)
MODEL
NO.
#3006F (BLACK)
REP.HANDLES
(INDUSTRIAL)
MODEL
NO.
#3006M (ALUM)
REP.HANDLES
(STAINLESS)
MODEL
NO.
# 3006I (STAINLESS)
REP.HANDLES
(CLUB)
MODEL
NO.
#3006C (ALUM)
ROLLERBOLT
(STAINLESS )
MODEL
NO.
#6004R-I40
(1 1/2" LONG)
CYLINDER
(BLANK )
MODEL NO.
#3012DSA
LOCINOX ACCESSORIES & INSTALLATION TIPS
MODEL NO.
# 3006PUSH
(ALUMINUM)
P
ush-Set in aluminum
Exit shown installed with lock.
Lock is Not included.
(FITS INDUSTRAIL LOCK & FREE EXIT
MECHANICAL CODE LOCK ONLY)
*The set is adaptable on all stainless
steel locinox locks with u-lockbox
*The push-set replaces the handles
*Facilitates the opening of the gate
3” WIDE
HALF SIDE ONLY
REP.HANDLES
(KNOB)
MODEL
NO.
#3006R (ALUM)
REP.HANDLES
(REINFORCED)
MODEL
NO.
#
3006S
(ALUM)
Aluminum handle blocking set
MODEL NO.
#
3006KR
(ALUM)
*The kits permits the following combinations
*1 side fixed-1 side movable-1-side blinded
*2 sides fixed
*2 sides movable
*Free exit & Store room applications
MODEL NO.
# 3006WSI
Security knobs for smimming pools,playgrounds
Its requires two simultaneous actions to release the
lock which avoids the access of children to the pool or
any other places where access must be controlled.
Works with all swinging gate locks
*polyamide
*conforms to swimming pool standard NF P90-306
*We strongly advise you to read the swimming pool standard
NF P90-306 before manufacturing any swimming pool gate.
*Works with all swinging locks with a square of 8mm
*Available in the following color. BLACK
Cylinders for locks with three keys
CYLINDERS
1 1/2"
MODEL NO.
3012VCA
(KEYED DIFFERENT)
3012GCA
(KEYED ALIKE)A
3012GCB
(KEYED ALIKE)B
3012GCC
(KEYED ALIKE)C
3012GCD
(KEYED ALIKE)D
CYLINDERS
2"
MODEL NO.
3012VSZ
(KEYED DIFFERENT)
3012GSZ
(KEYED ALIKE)Z
3012GSX
(KEYED ALIKE)X
3012GSY
(KEYED ALIKE))Y
CYLINDERS
2 1/2"
MODEL NO.
3012V33Z
(KEYED DIFFERENT)
3012G33Z
(KEYED ALIKE)A
CYLINDERS
3"
MODEL NO.
3012V44Z
(KEYED DIFFERENT)
3012G44Z
(KEYED ALIKE)A
SPLIT SHAFT
keyway with 2 blocking
washers and 2 hole plugs
MODEL
NO.
#3006BLOCK
keyway,Half handle
set,with plug
MODEL NO.
#3006HK
REP.HANDLES
(ADA)
MODEL NO.
#3006ADA
(ALUM)
FULL SET 90 MM,
ADA COMPLIANT
ROLLERBOLT
(STAINLESS )
MODEL
NO.
#6004R-I30
(1 1/4"LONG)
REKEYABLE Cylinders for
locks with two keys(Chrome)
CHILD SAFETY
KNOB
ROLLERBOLT
(STAINLESS )
MODEL
NO.
#6004R-I60
(2 1/2" LONG)
FITS
LSKZ
LOCKS
ONLY
REP.HANDLES
(ALUMINUM)
MODEL
NO.
#3006D (ALUM)
*Anodized black, aluminum Push bar with stainless steel mechanism
*Pressing the Push bar operates the Latch bolt
*Ideal in combination with Free Vinci lock
*For left and right turning gates
*Easy to install on the gate with Quick-Fix
*Delivered with half 8 mm spindle
*Possible to combine with half handles on the back side of the lock
*Maximum width: 53 inches
*Push bar length - standard 45 inches (can be shortened)
*Dummy cylinder recommended
PANIC bar for easy opening of the gate by a simple push for Safety Exit applications.
The Push bar replaces the normal handle, operates the latch bolt and can quickly be
installed on a new or existing Locinox Industrial Code Lock,LAPQU,LAKQU or
aSingle Sided Mechanical Code Lock LFPQX,LFKQX
MODEL# PUSHBAR-L
FITS
LAPY,
LAKY,
LAPQ,
LAKQ
LOCKS
Replacement Handles Fits all locks swing out gate locks
MODEL # STYLE SIZE
#3012KS-5P Kwikset,5 pin,DC,26D,2 1/2”
#3012SX-5P Schlage SX,5 pin (C-K)26D,2 1/2”
#3012SX-6P Schlage SX,6 pin (C-K)26D,2 3/4”
#3012SC-5P Schlage SC, 5 pin,26D.2 1/2”
#3012SC-6P Schlage SC, 6 pin,26D,2 3/4”
MODEL NO.
# 3970USA
(DRILLING JIG FOR SWINGATE LOCKS) DRILLING JIG FOR FASTER AND
EASIER INSTALLATION*Drilling jig for:LAKY,LAKQ,LEKQ,LFKQ locks and
SA/SH/SM keeps*Adjustable for
profiles for :1",1 1/4",1 1/2",1 3/4",2",2 1/2" of the width of the material
MODEL NO.
# 3970LS
(DRILLING JIG FOR SLIDE GATE LOCKS)
DRILLING JIG FOR FASTER AND EASIER INSTALLATION
*Drilling jig for:LSKZ & LLKZ locks and SSKZ/SSKO keeps
*Adjustable for profiles for :1 1/2",2",2 1/2" of the width of the material
Close-Out
(Non Refundable)
