Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
LOCINOX MECHANICAL & SWIMMING POOLS LOCKS & ACCESSORIES FOR GATES
Note: Special Order Cylinders are avaible in Schlage,Kwikset,Medeco & Best sfic
(small format interchangeable core)
MODEL
NO. FRAME/THICKNESS COLOR
#LMPQ10VBL.............1/2” to 1"
Thick.....
........................BLACK
#LMPQ10VSL.............1/2” to 1”
Thick......
........................SILVER
#LMKQ30VBL............1-1/4"
Thick.............
........................BLACK
#LMKQ30VSL ............1-1/4”
Thick..............
........................SILVER
#LMKQ40VBL............1-1/2" to 2”
Thick.
........................BLACK
#LMKQ40VSL.............1-1/2” to 2”
Thick.
........................SILVER
#LMKQ60VBL............2 1/2” to 3”
Thick..
........................BLACK
#LMKQ60VSL ............2 1/2" to 3”
Thick.
........................SILVER
MODEL #
IN COLOR BLACK COMES
SILVER HANDLES & BLACK BOX
&
MODEL #
IN COLOR SILVER COMES
WITH THE SILVER HANDLES &
SILVER BOX
Two Sided Mechanical Code
Lock With a
Deadbolt & Latch
LOCINOX LOCK FOR SWING GATES
MECHANICAL CODE LOCK-STAINLESS STEEL
*100% mechanical:no battery or electricity required
*Operational one code panel on each side
*Independent entrance and exit codes
*Equipped with aluminium dust and rain covers
*Easy and fast set-up or modification of the access codes
*With adjustable rollerbolt for easy closing
*Possibility of setting up 4 to 6 digit codes
*Extremely strong and user-friendly mechanism
*Automatic code reset after opening with the handle
*Anti-code detection with integrated security press plate
*Lockbox 1 1/4” X 3 3/4” Wide
*The latch bolt has 3/4” continuous adjustment to allow
perfect alignment of the locking m0echanism
*The standard & security keepers require a 1 1/4 latch gap
R
ecommended
K
eeps
ANCHORING SECURITY GATE STOP & KEEPER FOR SWING GATES
MODEL
NO. MIN.SIZE MAX SIZE COLOR MOU
NT
#
SHKLQFBL
........1-1/2"............>...................... BLACK..... QUICK-FIX
#
SHKLQFAL
........1-1/2"............>...................... ALUM...... QUICK-FIX
MODEL
NO
#6403
ROUND ADAPTOR PLATE
FOR SH KEEPERS
STANDARD GATE STOP & KEEPER FOR SWING GATES
MODEL
NO. MIN.SIZE MAX SIZE COLOR MOU
NT
#
SAKLQFBL
....... 1-1/2".............>........................BLACK.....QUICK-FIX
#
SAKLQFAL
....... 1-1/2".............>........................ALUM.......QUICK-FIX
STOP &
KEEPER
Gap Between
Post & Gate
Is 1 1/4"
MODEL
NO.
#
3018LA
ROUND ADAPTOR PLATE
FOR SA KEEPERS
R
ecommended
K
eeps
R
ecommended
K
eeps
LOCINOX LOCK FOR SWIMMING POOLS
*Lock:Stainless steel mechanism.
*Casting and knob: aluminum powdercoated and polyamide
*Stainless steel rollerbolt:facilitates the closing of the gate
*A totally new concept combing quality,aesthetic,easy
fitting and security for your small gates conforms to
swimming pool standard NF P90-306
*We strongly advise you to read the swimming pool standard
NF P90-306 before manufacturing any swimming pool
gate.
*Only for gate profiles: 1 1/2" 14ga, or 16 gate
*Available in the following color. BLACK
MODEL NO.
# TWIST40
KEEPER FOR
SWIMMING POOL
LOCK
POLYAMIDE ONE PIECE FITS
1 1/2"SQ.
MODEL NO.
# STKQFBL
MODEL #
IN COLOR BLACK
THE HANDLES &
LOCK BOX IS BLACK
& MADE IN POLYAMIDE
NO ADJUSTMENT ON
THROW & LATCH
Gap Between Post &
Gate Is 1 1/4"
To upgrade the cylinders to Medeco &
Best sfic (small format interchangeable core)
will be done at the factory in
illinois which will include the
complete set with the new
cylinders. Example when ordering:
Order the model # of the lock &
& then
#3012BEST-V8
(U8Sl Lock Box,8e Housing,&
1 Const Core (Fits Lakq Style),
3 1/8”
NOTE:COMES IN SILVER
ONLY
