Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
LOCINOX LOCK FOR SWING GATES
INDUSTRIAL LOCK-STAINLESS STEE
L
*Stainless steel internal components.
No ferrous materials
*Cast aluminum lockbox,lock body width 3 1/2”
*Two piece stainless steel latch bolt and deadbolt.
:LH/RH reversible form outside the lockbox
:Throw length: 1”
:Latch bolt/dead bolt adjustment 3/4”
*The standard & security keepers require a 1 1/4 latch gap
*Europrofile double cylinder w/3 keys,nickel
:Yale Y220 compatible
:Available keyed alike or keyed differently
:Key operated latch bolt (spring latch function)
*Four hole mounting; Fast & Easy
:Two mount bolts,recessed socket head bolts 8mm
:Two “through gate frame”latch bolt & dead bolt holes
*Available in the following colors.
BLACK & SILVER
Industrial lock for swing gates
(Check out handle description before ordering)
(Note:All The Lockboxes Are 1 1/4" Thick By Faceplate)
MODEL
NO. FRAME/THICKNESS COLOR
#
LAPQ10UBL
....3/8"-3/4”....................... BLACK
#
LAKQ30UBL
....1”-1 1/4"....................... BLACK
#
LAKQ30USL
....1”-1 1/4”........................ SILVER
#
LAKQ40UBL
....1-1/2" or 2". ................. BLACK
#
LAKQ40USL...
1-1/2” or 2”
................
SILVER
#
LAKQ60UBL
....2 1/2"-3” ...................... BLACK
#
LAKQ60USL...
2 1/2"-3”....................... SILVER
Left/Right hand reversible
Adjustable 3/4” continuous
stainless steel
LOCINOX INDUSTRIAL LOCKS FOR SWING GATES
Note:
The model # black
in color comes with the black
ornamental handles & black box
Chain Links Gate Kits
Industrial Lock for swing gates
kits Include:Lock And Security Keeper,
Round Adaptor Plates,& Chain Link Holder
(Check out handle description before ordering)
MODEL
NO. COLOR
#
LK30USL
Residential Gate Kit For 1 3/8" Gate
SILVER
#
LK40USL
Comercial Gate Kit For 1 7/8" Gate
SILVER
MODEL
NO.
#
3019LA
ROUND ADAPTOR PLATE
FOR LA & LS LOCKS
MODEL
NO.
#CLH....... SILVER
#CLHBL.. BLACK
chain link holder
Note: Note: Special Order Cylinders are avaible in Schlage,Kwikset,Medeco &
Best sfic (small format interchangeable core)
Note:
Recommended Keeps
#SHKLQFBL
#SHKLQFAL
#SAKLQFBL
#SAKLQFAL
(Description on the following pages)
To upgrade the cylinders to Medeco &
Best sfic (small format interchangeable core)
will be done at the factory in
illinois which will include the
complete set with the new
cylinders. Example when ordering:
Order the model # of the lock
& then
#3012BEST-U8
(U8Sl Lock Box,8e Housing,&
1 Const Core (Fits Lakq Style),
3 1/8”
NOTE:COMES IN SILVER
ONLY
Note:
The model # silver
in color comes with the silver handles
& silver box
