Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
I-Qwik Lite Series Mechanical Code Lock (FROM MARKS USA)
Lever Handle Mechanical Code Lock With
Passage Function.Available In Double Handle
Features:
*Handles:Brush Chome Finish *Body: Black Powder Coat
*CableGard Protects wires for easy installation
*Standard ANSI door prep with one dditional hole
*Pre-programmable
*Keypad programmed code
*160 User codes
*Temporary user codes
*Passage mode
*Pin only mode
*Double code entry for maximum security
*Two wire remote release
*16 Digit tactile metal keypad
*Weatherproof standard
*Audible & visible entry indicator
*Audible low battery alert
*4"AA"batteries,95,000 operations
*easy installation
*lifetime Mechanical Warranty;2 year Electronic Warranty
>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>
Door Thickness:1 3/4" STANDARD
Handing:Non-handed
Key Override:Marks "C"key.6 pin w/2keys
LOCK BODY Cylindrical "Survivor" featuring the
"CLUTCH) for trouble free service
LATCH: GRADE 2, 2 3/4" Backset,1/2" throw,3 Hour UL fire Rating
Strike Plate: 4 7/8" ASA strike
MODEL # K-BX
(FITS IQ1LITE)
14 ga.STEEL BOX
MODEL # K-BXAL
(FITS IQ1LITE)
.125 ALUMINUM BOX
8"
14"
1 3/4"
Note: Special Order Cylinders are avaible in Schlage,Kwikset,Medeco & Best sfic (small
format interchangeable core)
MODEL
NO. FRAME/THICKNESS COLOR
#LMPQ10VBL.............1/2” to 1"
Thick.....
........................BLACK
#LMPQ10VSL.............1/2” to 1”
Thick......
........................SILVER
#LMKQ30VBL............1-1/4"
Thick.............
........................BLACK
#LMKQ30VSL ............1-1/4”
Thick..............
........................SILVER
#LMKQ40VBL............1-1/2" to 2”
Thick.
........................BLACK
#LMKQ40VSL.............1-1/2” to 2”
Thick.
........................SILVER
#LMKQ60VBL............2 1/2” to 3”
Thick..
........................BLACK
#LMKQ60VSL ............2 1/2" to 3”
Thick.
........................SILVER
MODEL #
IN COLOR BLACK
COMES
SILVER HANDLES &
BLACK BOX
&
MODEL #
IN COLOR SILVER
COMES
SILVER HANDLES &
SILVER BOX
LOCINOX LOCK FOR SWING GATES
MECHANICAL CODE LOCK-STAINLESS STEEL
*100% mechanical:no battery or electricity required
* Operational one code panel on each side
*Independent entrance and exit codes
*Equipped with aluminium dust and rain covers
*Easy and fast set-up or modification of the access codes
*With adjustable rollerbolt for easy closing
*Possibility of setting up 4 to 6 digit codes
*Extremely strong and user-friendly mechanism
*Automatic code reset after opening with the handle
*Anti-code detection with integrated security press plate
*Lockbox 1 1/4” X 3 3/4” Wide
*The latch bolt has 3/4” continuous adjustment to allow
perfect alignment of the locking mechanism
*The standard & security keepers require a 1 1/4 latch gap
Marks, & Locinox Combination Locks For Pool Entry,Gates,Fences & Access Doors
Two Sided
Mechanical Code
Lock With a
Deadbolt & Latch
MECHANICAL FREE EXIT CODE LOCK FOR SWING GATES
(Note:All The Lockboxes Are 1 1/4" WIDE By Faceplate)
MODEL
NO. FRAME/THICKNESS COLOR
#LFPQ10XBL......... 1/2” to 1” Thick................... BLACK
#LFPQ10XSL.......... 1/2” to 1” Thick................... SILVER
#LFKQ30XBL......... 1-1/4” Thick......................... BLACK
#LFKQ30XSL ........ 1-1/4” Thick......................... SILVER
#LFKQ40XBL......... 1-1/2” to 2” Thick................ BLACK
#LFKQ40XSL......... 1-1/2” to 2” Thick................ SILVER
#LFKQ60XBL......... 2 1/2” to 3” Thick................ BLACK
#LFKQ60XSL ........ 2 1/2” to 3” Thick................ SILVER
#3006PUSH ............ Single Sided Push Lever..... SILVER
MODEL #
IN COLOR BLACK COMES WITH
SILVER HANDLES & BLACK BOX
&
MODEL #
IN COLOR SILVER COMES WITH
THE SILVER HANDLES & SILVER BOX
LOCINOX LOCK FOR SWING GATES
MECHANICAL CODE LOCK-STAINLESS STEEL
*100% mechanical:no battery or electricity required
*Operational code panel adjusts to each side
*Easy and fast set-up or modification of the access codes
*With adjustable rollerbolt for easy closing
*Possibility of setting up 4 to 6 digit codes
*Extremely strong and user-friendly mechanism
*Automatic code reset after opening with the handle
*Anti-code detection with integrated security press plate
*Lockbox 1 1/4” X 3 3/4” Wide
*The latch bolt has 3/4” continuous adjustment to allow
perfect alignment of the locking mechanism
*The standard & security keepers require a 1 1/4 latch gap
MODEL NO.
#
3006PUSH
(ALUMINUM)
Push-Set in SILVER
Exit shown installed with lock.
Lock is Not included.
(FITS INDUSTRAIL LOCK & FREE EXIT
MECHANICAL CODE LOCK ONLY)
*The set is adaptable on all stainless
steel locinox locks with u-lockbox
*The push-set replaces the handles
*Facilitates the opening of the gate
Single Sided
Mechanical Code
Lock With a Latch
Note:LOCKS COMES WITH
A LEVER ON FRONT &
KNOB ON REAR & ALSO
THERE IS NO DEADBOLT
ON THE FREE EXIT
MECHANICAL CODE LOCK
*Optional Push handle model
#3006push avaible for the
free exit side see below
MARKS USA
MODEL # M-LITE
