LOCINOX LOCKS & ACCESSORIES FOR SWING GATES
LOCK BOX IS
MADE IN ALUMINUM ONLY HAS
2 INSERTS TO BOLT THE BOX
TO FRAME SAME
PROFILE AS THE
ORNAMENTAL LOCK
Comes with keeper
Made for double leaf gates
FLAT KEEPER & LOCK BOX
MODEL
NO. MIN.SIZE MAX SIZE COLOR MOUNT
#SPKZ40BLTK....1-1/2"............2”....................BLACK....THROUGH
ANCHORING SECURITY GATE STOP & KEEPER FOR SWING GATES
MODEL
NO. MIN.SIZE MAX SIZE COLOR MOUNT
#SHKLQFBL........1-1/2"............>...................... BLACK..... QUICK-FIX
#SHKLQFAL........1-1/2"............>...................... ALUM...... QUICK-FIX
STANDARD GATE STOP & KEEPER FOR SWING GATES
MODEL
NO. MIN.SIZE MAX SIZE COLOR MOUNT
#SAKLQFBL....... 1-1/2".............>........................BLACK.....QUICK-FIX
#SAKLQFAL....... 1-1/2".............>........................ALUM.......QUICK-FIX
STOP &
KEEPER
MODEL
NO
#6403
ROUND ADAPTOR PLATE
FOR SH KEEPERS
MODEL
NO
#3018LA
ROUND ADAPTOR PLATE
FOR SA KEEPERS
GATE STOP & GATE CATCH OPTIONS
MODEL
NO. MIN.SIZE MAX SIZE COLOR MOUNT
#SFKL40BL....... 1-1/2"............2 1/2.................BLACK....THROUGH
GATE STOP & GATE CATCH OPTIONS
MODEL
NO. MIN.SIZE MAX SIZE COLOR
#SAKZ40BL ......... 1-1/2">............2"...................BLACK
QUICK-FIX
1 1/2”LONG
DRILL 9/16-5/8
HAMMERED
&
SCREW
INTO
FRAME
MODEL
NO
#QF2
(2 PER-SET)
Lock Installation Kit
MODEL
NO.
# IKIT60BL (BLACK)
Narrow Keeper For
Gap Between Post &
Gate Is 3/4"
(Fits Are Swing Gates)
Gap Between Post &
Gate Is 1 1/4"
Gap Between
Post & Gate
Is 1 1/4"
Gap Between
Post & Gate
Is 1/4"
NOTE:
This Kits Mounts The
Lock On The Face
Of The Gate Frame
& The Space Between
The Picket & Gate
Frame Is 1 1/2" Gap Between Post &
Gate Is 1/2"
Gap Between Post &
Gate Is 3/8"
1 3/16"
6 1/4"
2 15/16"
4 3/4"
MODEL
NO.
#3019LA
ROUND ADAPTOR PLATE
FOR LA & LS LOCKS
MODEL
NO.
#CLH....... SILVER
#CLHBL.. BLACK
chain link holder
OPEN
CLOSED
Installation Tips:
1:Drill straight through the gate frame.
The holes for the latch bolt and the dead bolt need to be straight through the frame or the bolts will not
move freely once installed.If the holes aren’t straight,you will neeed to drill a larger hole on the inside
gate frame to free up the latch bolts.
2:The Big hole (5/8”)goes on the outside of the gate frame.The Small hole (3/8”)goes on the inside.
3:Locinox locks and keepers work with face mounted hinges or center mounted hinges.
4:Use the provided drilling template or purchase a drilling jig (#3970USA or #3970lS)to simplify the installation.
