Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
LOCINOX LOCK FOR SLIDING GATES
SLIDING GATE LOCK-STAINLESS STEEL
*
Chassis,mechanism and twistfinger in stainless steel
*Reversible twistfinger (catch bolt)
*Innovative closing system
*three hole mounting; Fast & Easy
:Two mount bolts,recessed socket head bolts 8 mm
:One “through gate frame”catch bolt hole
*Stainless steel collar around the twistfinger prevents
cutting the twistfinger
*Lockbox width:3 1/2"
MODEL # THICKNESS
7015-40
...........FITS 1 1/2”
#
7015-50
.........FITS 2”
#
7015-60
.........FITS 2 1/2”
#
7015-80.......
FITS 3”
#
7015-100
.......FITS 4”
#
7015-120.....
FITS 5”
CATCH BOLT TO
FIT 1 1/2 TO 5”
CATCH BOLT
“TWIST FINGER “
FRONT VIEW
LOCINOX LOCK,MECHANICAL LOCKS & ACCESSORIES FOR SLIDING GATES
MODEL
NO.
#
OSET
STAINLESS STEEL
BACK COVER BOX
MODEL
NO.
#
SSKO
(SLIDING GATE KEEP)
*Includes the OSET & SSKZQF
*Keep in stainless steel for flat profiles
*Can be mounted with the stainless steel casing
in front of or behind the profile
*The keep is 3/8" left/right auto-adjustable
for easy and secure anchoring of the
lock-twistfinger
*The rubber stop prevents damaging the gateframe
MODEL
NO.
#
SSKZQF
(SLIDING GATE KEEP)
*Keep in stainless steel for square profiles
*Minimum profile size:3" wide
*The keep is 3/8" left/right auto-adjustable
for easy and secure anchoring of the
lock-twistfinger
*The rubber stop prevents damaging the gateframe
MECHANICAL CODE LOCK FOR SLIDING GATES
(Note:All The Lockboxes Are 1 1/4" Thick By Faceplate)
MODEL
NO. FRAME/THICKNESS COLOR
#LLKZXXUBL....... 1 1/2">.................................. BLACK
________________________________________________
#LLKZXXUSL........ 1 1/2">.................................. SILVER
NOTE:CATCH BOLT
SOLD & ORDER
SEPERATE
FOR THIS TYPE OF
LOCK
HANDLE STYLE
SAME AS PICTURE
Note:
The model #
black in color comes
with a silver handles &
black box
&
The model #
silver in color comes
with the silver handles &
silver box
LOCINOX LOCK FOR SLIDING GATES
MECHANICAL CODE LOCK-STAINLESS STEEL
*100% mechanical:no battery or electricity required
*Operational code panel on both sides
*Independendent entrance and exit codes
*Equipped with aluminium dust and rain covers
*Easy and fast set-up or modification of the access codes
*Possibility of setting up 4 to 6 digit codes
*Extremely strong and user-friendly mechanism
*Automatic code reset after opening with the handle
*Stainless steel collar around the twistfinger prevents
cutting the twistfinger.
*Lockbox width:3 5/8"
*Cylinder dustcover available (optional)Model # DC
CATCH BOLT TO
FIT 1 1/2 TO 5”
CATCH BOLT
“TWIST FINGER “
FRONT VIEW
LOCK FOR SLIDING GATES
(Note:All The Lockboxes Are 1 1/4" Thick By Faceplate)
MODEL
NO. FRAME/THICKNESS COLOR
#
LSKZXXUBL
.... 1 1/2">.................................. BLACK
________________________________________________
#
LSKZXXUSL
.... 1 1/2">.................................. SILVER
MODEL # THICKNESS
7015-40
...........FITS 1 1/2”
#
7015-50
.........FITS 2”
#
7015-60
.........FITS 2 1/2”
#
7015-80.......
FITS 3”
#
7015-100
.......FITS 4”
#
7015-120.....
FITS 5”
2 9/16'
6 3/4"
2"
Two Sided Mechanical Code
Lock With a
Deadbolt & Latch
R
ecommended
K
eeps
for
S
liding gate
R
ecommended
A
dapter
case
for
S
liding gate
REPLACEMENT HANDLES SOLD
IN PAIRS
MODEL
# 3006D
OR
MODEL
# 3006S
ON THE
FOLLOWING PAGE
REPLACEMENTS HANDLES SOLD IN PAIRS
MODEL
# 3006C
ON THE FOLLOWING PAGE
NOTE:CATCH BOLT
SOLD & ORDER
SEPERATE
FOR THIS TYPE OF
LOCK
HANDLE STYLE
SAME AS PICTURE
Note:
The model #
black in color comes
with a silver handles &
black box
&
The model #
silver in color comes
with the silver handles &
silver box
