Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
TRU-CLOSE HINGES FOR SWING GATES
MODEL NO. APPLICATIONS color
TCHDMA1... .......
LARGE OR HEAVY VINY/WOOD GATE.........BLACK
TRUCLOSE (HEAVY DUTY) MULTI- ADJUSTABLE SELF-CLOSING
GATE HINGES FOR LARGE SQUARE FRAME GATES
FEATURES OF THE HINGES
*3-WAYADJUSTMENT-VERTICAL,HORIZONTAL & TENSION
*SUPER-STRONG ENGINEERING POLYMER AND STAINLESS STEEL CONSTRUCTION
*HEAVY DUTY HINGE FOR LARGE VINYL OR WOOD GATES
*UP TO 3/4” (19MM) ADJUSTMENT
SOLD IN PAIRS ONLY
NOTE:
paint voids warranty
each multiadjust hinge has
two wrap
-
around
(90
˚
double
face
-
fixed
)
mounting
brackets
:
one
that
fits
to
the
gate
frame and another
to
the
fence
post
.
stainless
steel
”
studs
”
within
the
brackets allow a
lone
installer
to
lift a heavy gate
into
position and
secure
it with
ease
TRUCLOSE (HEAVY DUTY) SELF-CLOSING GATE HINGES FOR ROUND GATE FRAME
FEATURES OF THE HINGES
*HEAVY DUTY HINGES SELF-CLOSE GATES UP TO 132 LBS(60KG)
*SUPER-STRONG ENGINEERING POLYMER AND STAINLESS STEEL CONSTRUCTION
*IDEA FOR HIGH-TRAFFIC GATES
*EACHPAIR OF HINGES IS PACKAGED AS A KIT THAT INCLUDED SHIMS/ADAPTORS
TO FIT AVARIETY OF POST AND GATE DIAMETERS
*ADJUSTS HORIZONTALLYAND FOR TENSION
*UNIQUE,PATENTED TENSION ADJUSTMENT
*INTERNAL STAINLESS STEEL SPRING
*UV-STABILIZED,”SELF-LUBRICATING”MATERIALS
*ALIGNMENT LEGS AND ADJUSTMENTS SLOTS
*QUALITYASSURANCE ISO 9001 MANUFACTURER
MODEL NO. APPLICATIONS color
TCHDRND1-MK2..........
FOR DIFFERENT DIAMETER GATE FRAME & POST.............BLACK
TCHDRND2-MK2..........
FOR 2” ROUND RAILING SYSTEMS.............................................BLACK
FOR ROUND GATE FRAMES AND FENCE POSTS
TCHDRND1-MK2..........
FOR DIFFERENT DIAMETER
GATE FRAME & POST
GATE DIAM:1 3/8” & 1 5/8”
POST DIAM:1 7/8”,2 3/8”,2 7/8”
TCHDRND2-MK2..........
FOR
2” ROUND RAILING SYSTEMS
GATE DIAM:1 7/8”
POST DIAM:1 7/8”,2 7/8”
SOLD IN PAIRS ONLY
NOTE:
paint voids warranty
