SURECLOSE FLUSH MOUNTING
CODE FLUSH MOUNT BRACKET 0 - -SELF- MAX GATE FENCE POST POOL/CHILD
MODEL # MODEL/TYPE MATERIAL 0 - -CLOSING SWING SIZE SAFETY**
DESCRIPTION DESCRIPTION 0 - FROM DEGREE MINIMUM
DEGREE
75001213----- SureClose SM HINGE ONLY- ----------------------------------------ALUMINUMN SCREW-ON------ NO------------180- ------------- 2”--------------- -----
75057213M- - SureClose 57 HINGE CLOSER---------------------------------------ALUMINUMN SCREW-ON------ 85- ------------180- ------------- 2”--------------- -----
75057223M- - SureClose 57SF HINGE CLOSER-----------------------------------ALUMINUMN SCREW-ON------ 90- ------------ 90- ------------- 2”--------------- YES
75108213M- - SureClose108 HINGE CLOSER/FINAL SNAPACTION- -------ALUMINUMN SCREW-ON------ 85- ------------180- ------------- 3”--------------- ------
75108223----- SureClose108SF HINGE CLOSER/FINAL SNAPACTION-----ALUMINUMN SCREW-ON------ 90- ------------ 90- ------------- 3”--------------- YES
75001214M- - SureClose SM HINGE ONLY- ----------------------------------------STEELWELD-ON------------------ NO------------180- ------------- 2”--------------- -----
75057214M- - SureClose 57 HINGE CLOSER---------------------------------------STEELWELD-ON------------------ 85- ------------180- ------------- 2”--------------- -----
75057224M- - SureClose 57SF HINGE CLOSER-----------------------------------STEELWELD-ON------------------ 90- ------------ 90- ------------- 2”--------------- YES
75108214M- - SureClose108 HINGE CLOSER/FINAL SNAPACTION- -------STEELWELD-ON------------------ 85- ------------180- ------------- 3”--------------- ------
75108224M- - SureClose108SF HINGE CLOSER/FINAL SNAPACTION-----STEELWELD-ON------------------ 90- ------------ 90- ------------- 3”--------------- YES
*Gate mounting included with hinge.Post mounting brackets sold separately.Fasteners not included
**Use only SF model closers on pool/safety gates.Hinges must be at least 36” (900mm) apart so that they cannot be used as footholds by toddlers
IMPORTANT:For maximum gate weights check the page
CAUTION:A .gate stop must be installed when using models.Gate must not be allowed to open past 90 degrees.doing so voids warranty.
