SURECLOSE CENTER MOUNTING
CODE CENTER MOUNT BRACKET 0 - -SELF- MAX GATE FENCE POST POOL/CHILD
MODEL # MODEL/TYPE MATERIAL 0 - -CLOSING SWING SIZE SAFETY**
DESCRIPTION DESCRIPTION 0 - FROM DEGREE MINIMUM
DEGREE
75001113- ---- SureClose SM HINGE ONLY- ----------------------------------------ALUMINUMN SCREW-ON------ NO------------ 90- ------------- 2 1/2”---------- -----
75057113M--- SureClose 57 HINGE CLOSER---------------------------------------ALUMINUMN SCREW-ON------ 85- ------------ 90- ------------- 2 1/2”---------- -----
75057123M- - SureClose 57SF HINGE CLOSER-----------------------------------ALUMINUMN SCREW-ON------ 90- ------------ 90- ------------- 2 1/2”---------- YES
75108113M--- SureClose108 HINGE CLOSER/FINAL SNAPACTION- -------ALUMINUMN SCREW-ON------ 85- ------------ 90- ------------- 3”--------------- ------
75108123M- - SureClose108SF HINGE CLOSER/FINAL SNAPACTION-----ALUMINUMN SCREW-ON------ 90- ------------ 90- ------------- 3”--------------- YES
75001114- ---- SureClose SM HINGE ONLY- ----------------------------------------STEELWELD-ON------------------ NO------------ 90- ------------- 2 1/2”---------- -----
75057114M--- SureClose 57 HINGE CLOSER---------------------------------------STEELWELD-ON------------------ 85- ------------ 90- ------------- 2 1/2”---------- -----
75057124M- - SureClose 57SF HINGE CLOSER-----------------------------------STEELWELD-ON------------------ 90- ------------ 90- ------------- 2 1/2”---------- YES
75108114M--- SureClose108 HINGE CLOSER/FINAL SNAPACTION- -------STEELWELD-ON------------------ 85- ------------ 90- ------------- 3”--------------- ------
75108124M- - SureClose108SF HINGE CLOSER/FINAL SNAPACTION-----STEELWELD-ON------------------ 90- ------------ 90- ------------- 3”--------------- YES
*Gate mounting included with hinge.Post mounting brackets sold separately.Fasteners not included
**Use only SF model closers on pool/safety gates.Hinges must be at least 36” (900mm) apart so that they cannot be used as footholds by toddlers
IMPORTANT:For maximum gate weights check the page
CAUTION:A .gate stop must be installed when using models.Gate must not be allowed to open past 90 degrees.doing so voids warranty.
