Catalog 23 - page 206

206
Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
www.orleansornamental.com
CLICK HERE FOR
THE TABLE OF CONTENTS
SURECLOSE SELF CLOSE HINGES CENTER MOUNTED FOR SWING GATES
SureClose SM
NON SELF CLOSING
SureClose 57
ADJUSTABLE
SELF CLOSING
SureClose 108
ADJUSTABLE SELF CLOSING
WITH FINAL SNAPACTION
CODE CENTER MOUNT BRACKET 0 - -SELF- MAX GATE FENCE POST POOL/CHILD
MODEL # MODEL/TYPE MATERIAL 0 - -CLOSING SWING SIZE SAFETY**
DESCRIPTION DESCRIPTION 0 - FROM DEGREE MINIMUM
DEGREE
75001113- ---- SureClose SM HINGE ONLY- ----------------------------------------ALUMINUMN SCREW-ON------ NO------------ 90- ------------- 2 1/2”---------- -----
75057113M--- SureClose 57 HINGE CLOSER---------------------------------------ALUMINUMN SCREW-ON------ 85- ------------ 90- ------------- 2 1/2”---------- -----
75057123M- - SureClose 57SF HINGE CLOSER-----------------------------------ALUMINUMN SCREW-ON------ 90- ------------ 90- ------------- 2 1/2”---------- YES
75108113M--- SureClose108 HINGE CLOSER/FINAL SNAPACTION- -------ALUMINUMN SCREW-ON------ 85- ------------ 90- ------------- 3”--------------- ------
75108123M- - SureClose108SF HINGE CLOSER/FINAL SNAPACTION-----ALUMINUMN SCREW-ON------ 90- ------------ 90- ------------- 3”--------------- YES
75001114- ---- SureClose SM HINGE ONLY- ----------------------------------------STEELWELD-ON------------------ NO------------ 90- ------------- 2 1/2”---------- -----
75057114M--- SureClose 57 HINGE CLOSER---------------------------------------STEELWELD-ON------------------ 85- ------------ 90- ------------- 2 1/2”---------- -----
75057124M- - SureClose 57SF HINGE CLOSER-----------------------------------STEELWELD-ON------------------ 90- ------------ 90- ------------- 2 1/2”---------- YES
75108114M--- SureClose108 HINGE CLOSER/FINAL SNAPACTION- -------STEELWELD-ON------------------ 85- ------------ 90- ------------- 3”--------------- ------
75108124M- - SureClose108SF HINGE CLOSER/FINAL SNAPACTION-----STEELWELD-ON------------------ 90- ------------ 90- ------------- 3”--------------- YES
