SURECLOSE/READYFIT EXTERNALLY MOUNTING
CODE CENTER MOUNT BRACKET 0 - -SELF- MAX GATE FENCE POST POOL/CHILD
MODEL # MODEL/TYPE MATERIAL 0 - -CLOSING SWING SIZE SAFETY**
DESCRIPTION DESCRIPTION 0 - FROM DEGREE MINIMUM
DEGREE
74001313----- SureClose RM/SM HINGE ONLY------------------------------------ ALUMINUMN SCREW-ON----- NO------------ 180------------- 2”--------------- -----
74108313----- SureCloseRF/108 HINGE CLOSER/FINAL SNAPACTION---- ALUMINUMN SCREW-ON----- 85- ------------ 180------------- 2”--------------- ------
74108323----- SureCloseRF/108SF HINGE CLOSER/FINAL SNAPACTION- ALUMINUMN SCREW-ON----- 90- ------------ 90------------- 2”--------------- YES
74001315----- SureCloseRF/SM HINGE ONLY-------------------------------------- STEELWELD-ON---------------- NO------------ 180------------- 2”--------------- -----
74108315----- SureCloseRF/108 HINGE CLOSER/FINAL SNAPACTION---- STEELWELD-ON---------------- 85- ------------ 180------------- 2”--------------- ------
74108325----- SureCloseRF/108SF HINGE CLOSER/FINAL SNAPACTION- STEELWELD-ON---------------- 90- ------------ 90------------- 2”--------------- YES
NOTICE:
GAP VARIANCE
1/2”-1 3/8”
NOTICE:
GAP VARIANCE
1/2”-1 3/8”
**Yes (SF)=Gate will not hold open at 90 degrees (OK for safety gates)Do NOT use a hinge with a 90 degree hold-open feature (-)for pool/child safety gates.
IMPORTANT:For maximum gate weights check the page
CAUTION:A .gate stop must be installed when using models.Gate must not be allowed to open past 90 degrees.doing so voids warranty.
