Catalog 23 - page 219

219
Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
www.orleansornamental.com
CLICK HERE FOR
THE TABLE OF CONTENTS
BARREL HINGES
TYPE OF MODEL HEIGHT ROUND WEIGHT STAINLESS CLEARENCE
MATERIAL NUMBER SIZE SIZE CAPACITY STEEL PIN BETWEEN
PER/PAIR SIZE GATE & POST
STEEL- -------------# BRHS5- -------------- 5”-----------1”----------600 LBS- -------- 5/8”---------------1 3/4”
STEEL- -------------# BRHS7-8------------- 7”-----------1 3/8”------900 LBS- -------- 3/4”---------------2”
STEEL- -------------# BRHS7-212---------- 7”-----------2 1/2”------3000 LBS-------- 1 1/4”- -----------3 3/4”
MODEL # BRHJ5
5”
500 LBS MAX/PAIR
MODEL # HDRBH3
3”
SEALED BEARING
180 DEGREE SWING
1400 LB MAX/PAIR
MODEL # BRHJ7
8”
900 LBS MAX/PAIR
MODEL # HDRBH4
4”
SEALED BEARING
180 DEGREE SWING
1700 LB MAX/PAIR
DESIGNED FOR ACTIVE & HEAVY GATES
THIS HINGE HAS SEALED BEARING
REQUIRING NO MAINTENANCE OR GREASE.
DEPENDABLE & EASY TO INSTALL
ADJUSTABLE
J-BOLT
BARREL HINGES
MADE IN THE USA
(SOLD IN PAIRS ONLY)
MADE IN THE USA
(SOLD IN PAIRS ONLY)
STAINLESS STEEL PIN WITH BALL BEARING
STEEL BARREL HINGES
ROLLER BEARING
HINGES
MADE IN THE USA
(SOLD IN PAIRS ONLY)
2 3/4” 4 1/4”
8 3/8” 5 1/2”
3 1/2” 4 1/4”
5/8”
BOLT
3//4”
BOLT
3/8”x 1”
FLAT
BAR
1”
RD.
BAR
3/8”x 1 1/2”
FLAT
BAR
1 3/8”
RD.
BAR
STEEL BARREL,ROLLER BEARING & J-BOLT HINGES
