222
Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
SOLD IN PAIRS
MODEL # 1010T
2 1/4” x 3 1/2”
MODEL # 315T
FEMALE
1/2" HOLE
MODEL # 317T
MALE
FITS 1/2" HOLE
2 1/4”
STEEL BARREL,BAT WING ,J-BOLT,BUTT,H HINGES & SCREEN & GLASS CLIP
MODEL # 325T
FEMALE
5/8" HOLE
MODEL # 327T
MALE
FITS 5/8" HOLE
BAT WING HINGES
SOLD EACH
SOLD EACH
.36 LBS
MODEL # 1403BH
3”HIGH
(BARREL HINGES)
3/4” RD. x 3”
1/2”
STEEL
PIN
STEEL HINGES
2 1/4” x 3 1/2”
NO HOLES
.097 GAUGE
FIX PIN
SOLD IN PAIRS
6.36 LBS
MODEL # 1407BH
7” HIGH
SOLD IN PAIRS
2.70 LBS
MODEL # 1405BH
5 1/8” HIGH
MODEL # 6100
(BLACK CAST)
SCREEN &
GLASS CLIP
PROJECTION IS
3/8”
BLACK CAST
(BARREL HINGES)
STAINLESS
PIN WITH BALL
BEARING
& GREASE
FITTING
ON BOTTOM
(BARREL HINGES)
STAINLESS
PIN WITH BALL
BEARING
& GREASE
FITTING
ON BOTTOM
STEEL HINGES-NO HOLES-FIX PIN
SOLD IN PAIRS
MODEL # 329T
FEMALE
3/4" HOLE
MODEL # 331T
MALE
FITS 3/4" HOLE
SOLD IN PAIRS
2.64 LBS
MODEL # ABH-5
BOLT LENGTH:
4 3/8"
5/8" STEEL J-BOLT
SOLD IN PAIRS
6.50 LBS
MODEL # ABH-7
BOLT LENGTH:
6 3/4"
3/4" STEEL J-BOLT
GREASE
FITTING
ON BOTTOM
GREASE
FITTING
ON BOTTOM
SOLD IN PAIRS
1.20 LBS
MODEL # 1013T
2 5/8 x 7” HIGH
FIX PIN WITH
BRASS BUSHINGS
BLACK FINISH
MODEL # 1950T
1/2” X 4 1/2"
MODEL # 19625
5/8” X 4 1/2"
MODEL # 19735
3/4” X 7"
1 1/4”
1”
1”
BAT WING HINGES
SOLD EACH
2”
1 7/8”
1 7/8”
1 1/4”
1”
1”
MODEL Steel
NO. Description Thickness
1009T. ........ 3" x 3".................. ...(.092)
1011T.......... 3 1 /2” x 3 1/2”..... ...(.097)
1014H......... 4” x 4”.................... ...(.178)
1015H......... 5” x 5”.................... ...(.198)
1016H......... 6” x 6”................... ...(.198)
(BARREL HINGES)
STEEL
PIN WITH BALL
BEARING
& GREASE
FITTING
ON BOTTOM
BARREL PART
IS 2” RD.
2” RD.
SOLD IN PAIRS
14.22 LBS
MODEL # 1409BH
9”HIGH
SOLD IN PAIRS
MODEL # 1012SH
4” x 4”
SINGLE ACTION
SPRING
STEEL HINGES
4” x 4”
NO HOLES
3/8” PIN
