CONNECTORS FOR 1 1/2” SCH. 40 PIPE”
COPED DRIVE ON WELDING CONNECTORS &
SOCKET WELD FITTING
(FOR 1 1/2” SCH.40 PIPE)
NO MORE PIPE COPING NECESSARY
# 1834-A
FITS 1 1/2”
SCH-40-PIPE
WELD & GRIND
SIZE OF SCHEDULE 40
PIPE
FOR 1 1/2”
I.D=1.610”
OD=1.900”
SIZE OF SCHEDULE 40
PIPE
FOR 1 1/2”
I.D=1.610”
OD=1.900”
# 1838-B
FITS 1 1/2”
SCH-40-PIPE
# 1842-C
FITS 1 1/2”
SCH-40-PIPE
90° TEE CONNECTOR CORNER TEE
# 820-E
FITS 1 1/2”
SCH-40-PIPE
# 841-ES
FITS 1 1/2”
SCH-40-PIPE
# 873-C
FITS 1 1/2”
SCH-40-PIPE
# 865-T
FITS 1 1/2”
SCH-40-PIPE
# 869-SOT
FITS 1 1/2”
SCH-40-PIPE
WELD
&
GRIND WELD
&
GRIND
SIDE OUTLET TEE
FLUSH END CAPS,COVER CAPS, & FLANGES
(FOR 1 1/2” SCH 40 PIPE)
# 3229-D
(WELD & GRIND)
FITS 1 1/2”
SCH-40-PIPE
1 1/8”
3/16” 1/2” 1 1/8” 1/2”
# 3212-A
(DRIVE ON)
FITS 1 1/2”
SCH-40-PIPE
# 3229-F
(WELD & GRIND)
FITS 1 1/2”
SCH-40-PIPE
# 3220-C
(WELD & GRIND)
FITS 1 1/2”
SCH-40-PIPE
# 3212-H
(DRIVE ON)
FITS 1 1/2”
SCH-40-PIPE
4 1/2” 4 1/2”
# 2534
(PLAIN)
FITS 1 1/2”
SCH-40-PIPE
# 2535A
(3 HOLES 5/16")
FITS 1 1/2”
SCH-40-PIPE
SNAP TOGETHER
PLASTIC
BLACK SHOES
# PRD-112
(PLASTIC BLACK)
FITS 1 1/2”
SCH-40-PIPE
3/8”
THICKNESS
OF FLANGES
.134”
3/8" hole 5/16" holes
Model NO. OF O.D. WALL A B C D
Number HOLES THICK.
1133-1.......one.......... 1.900"..... .145........... 4.44"...... 2.05"..... 3.00"...3.50"
1164-1.......one.......... 1.900"..... .145........... 4.44"...... 2.30"..... 3.25"...3.50"
1133-2.......two.......... 1.900"..... .145........... 2.94"...... 2.05"..... 3.00"...4.44"
1164-2.......two.......... 1.900"..... .145........... 2.94"...... 2.30"..... 3.25"...4.44"
Model O.D. BEVEL DIM.TO DIM.TO
Number CENTER CENTER
B C
1883-32....... 1.660"......... 32°............ 2.69"......... 2.28"
1880-36....... 1.660"......... 36°............ 2.69"......... 2.18"
1882-45....... 1.660"......... 45°............ 2.69"......... 1.90"
32°, 36° 45°
Beveled Connectors
90°
elbow
side
outlet
elbow
cross
tee side
outlet
tee
2 3/4" 2 1/2"
3 1/2"
2 1/4"
3 1/2"
MADE IN
U.S.A.
MADE IN
U.S.A.
MADE IN
U.S.A.
MADE IN
U.S.A.
MADE IN
U.S.A.
REDERVED FOR NEW ITEMS
