PUZZLE-LOCK SPLIT FLANGE
*A UNIQUE CONCEPT FOR THE INSTALLATION OF COVER FLANGES AROUND EXISTING POSTS.
THE ANSWER TO THOSE “FORGOTTEN” COVERS * HIDES GROUT
*COVERS DISCOLORATION* COVERS RUST RING
THIS TWO PIECE FLANGE LOCKS TOGETHER TO APPEAR AS ONE
# W-26402
(SPLIT FLANGE)
FITS 1 1/4” PIPE
# W-26403
(SPLIT FLANGE)
FITS 1 1/2” PIPE
FLANGES & END CAPS FOR 1 1/4",1 1/2",2",2 1/2",3",3 1/2",4",6" SCH. 40 PIPE
PIPE SIZE WALL . MODEL
a
OF SCH.40 THICK. NUMBER
2 1/2"........... 10 ga.. ..... W-3224-C.................1 1/4"
3"................. 10 ga.. ..... W-3225-C.................1 1/4"
3 1/2"........... 10 ga.. ..... W-32252-C...............1 5/16"
4"................. 10 ga.. ..... W-32255-C...............1 5/8"
6" ................ 10 ga.. ..... W-32256-C...............2 5/8"
6"................. 1/4".. ....... W-3225C6-C.............2 11 1/6"
PIPE SIZE WALL . MODEL
a
OF SCH.40 THICK. NUMBER
2 1/2"........... .203"........ W-328825-E..............3/16"
3"................. .216"........ W-32883-E................3/16"
3 1/2"........... .120"........ W-328835-E..............1/8"
4"................. .237"........ W-32884-E................3/16"
6" ................ .280"........ W-32886-E................3/16"
PIPE SIZE
WALL MODEL a
w
Holes To h
OF SCH.40
THICK.
NUMBER
Center
1 1/4"...................... ..179".. ...........W-4811-2....... 4 1/4".......... 2 3/4"...........3 1/4"........... 3/4"
1 1/2"...................... ..179".. ...........W-4816-3....... 4 1/2".......... 3".................3 1/2"........... 7/8"
2"............................ ..179".. ...........W-4821-2....... 5"................ 3 1/2"...........4"................. 7/8"
MADE IN
U.S.A.
MADE IN
U.S.A.
MADE IN
U.S.A.
MADE IN
U.S.A.
DRIVE-ON
