226
Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
MODEL # 400W
(4”x 1 7/8” )
MODEL # 600W
(6” x 2 1/4”)
MODEL # 400W-BOX
MODEL # 600W-BOX
4 15/16”
3 1/8”
2 1/4”
FITS ON
1”x 1”
ANGLE
BOX TO FIT 6” GROVE
WHEEL 1/8” THICK
4” GROVE WHEEL
500 lb.Capacity
6” GROVE WHEEL
800 lb.Capacity
FITS ON
1”x 1”
ANGLE
GROVE WHEELS, BOXES,RUBBER ROLLERS,SWIVELWHEELS,& TRACKS
7”
4 1/16”
2 7/8”
STEEL
STEEL
* FOR JOBS WHERE YOU WANT TO MAKE A BIG IMPRESSION
* 3000 LBS OR 5000 LOAD CAPAITY
* FULLY SEALED STEEL BEARINGS NEED NO LUBRICATION
* PRECISION MACHINED FROM HIGHEST QUALITY COLD
ROLLED STEEL
* WEATHER RESISTANT ZINC PLATING
* 1/2” ZINC PLATED BOLT AND NUT
* RELIEF GROOVE SELF CLEANS
(4” OR 6" SOLID STEEL PRECISION V-GROOVE WHEEL)
FULLY SEALED STEEL BEARINGS NEED NO LUBRICATION
MODEL # 401NW
(4”x 2”)
FITS ON
1”x 1”
ANGLE
4” GROVE WHEEL (nylon)
500 lb.Capacity
CAST
IRON
4”
CAST
IRON
6”
NYLON
4”
Quiet & Smooth
MODEL # 127-HD
(SWIVEL WHEEL)
SPRING CASTER (HEAVY DUTY)
1.HARD RUBBER WHEEL.
2 3” DIAMETER WHEEL
3.MOUNTING PLATE 2” x 5 1/8”
WITH 5 HOLES
4.HEAVY COMPRESSION
SPRING (100 LBS.RATED)
MODEL # 129-S
(SWIVEL WHEEL)
SPRING CASTER (LIGHT DUTY)
1.HARD RUBBER WHEEL.
2 3” DIAMETER WHEEL
3.MOUNTING PLATE 1 7/8” x 2 5/8”
WITH 2 HOLES
4.LIGHT COMPRESSION
SPRING (25 LBS.RATED)
11”
1 3/4”
5 3/4”
2”
5 3/4”
10”
MODEL # 134-HD
(SWIVEL WHEEL)
1.HARD RUBBER WHEEL.
2 3” SWIVEL CASTER W/BEARING
3.HEIGHT: 16 3/4
4.HEAVY DUTY SPRING
5.MILL FINISH
MODEL # VTRACK
GROVE WHEEL TRACK
1/8" THICK x 4" WIDE x
20 FEET
(GALVANZIED)
MODEL
# VW-400
4"(3000 LBS)
MODEL # 400C-4
MODEL # 400C-2
OVERHEAD TRACK
WHEELWITH
BALL BEARING
HEAVY DUTY
OVERHEAD TRACK
4 STEELWHEELS
WITH
BALL BEARING
SLIDING
GALVANIZED
DOOR TRACK
MAX.CAPACITY
400 LBS
LENGTH MODEL
NUMBER
12'.............400C-12
24'.............400C-24
1 3/4"
2 1/4"
MODEL
# VW-600
6"(5000 LBS)
I.D..1 15/16”
I.D..2 9/16”
1/2”
1/2”
Grease Fitting
(Needs Grease)
Grease Fitting
(Needs Grease)
Fits
400W-BOX
GU-4BOX
GU-5BOX
Fits
600W-BOX
Fits
GU-5BOX
Fits
400W-BOX
GU-5BOX
Fits
600W-BOX
GU-6BOX
GU-8ALUM
BOX TO FIT
4” GROVE
WHEEL
1/8” THICK
MODEL
#
GU-
4BOX
W.-2 3/4"
MODEL
#
GU-6BOX
W-2 7/16”
BOX TO FIT 6”SEALED BEARING GROVE
WHEEL 1/8” THICK
ALUMINUM
GROVE WHEEL
BOX
STEEL
STEEL
BOX TO FIT 6” SEALED BEARING GROVE
WHEEL 1/8” THICK
MODEL #
GU-
5BOX
W.-2 1/2"
FITS THE VW-400
STEEL
4 3/4”
4 1/4”
5”
4 3/8”
1/2”
1/2”
5/8”
5/8”
13”
6 3/16”
7 1/16”
6 5/16”
MODEL
#
GU-8ALUM
W-2 1/2”
MADE IN THE USA
MADE IN THE USA
MADE IN THE USA
MADE IN THE USA
ALUMINUM
