Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
INSTALLATION:
GUARDIAN gate hinges are to be mounted with the yoke(fig.1)
welded to the gate and the plate welded to the post.The hinges
must be installed with the hinge pins in a straight line.two
hinges per gate leaf are recommended except in cases where
the gate exceeds 6' in height or 6' in width or weighs more than
400 pounds.In such cases additional hinges per leaf may be
added at the installer's discretion.Weld only on the vertical portions
of the yoke and plate.
DO NOT
weld the top and bottom of the hinges.
NOTE:
ALL GREASE FITTING
HAS TO BE LUBRICATED
FOR THE FIRST TIME WITH
AMULTI PURPOSE GREASE
AFTER THAT ONE PUMP
EVERY 3 MONTHS
SHOULD BE SUFFICIENT
UNDER NORMAL
OPERATING CONDITIONS
NOTE:
ALL HINGES
ARE
PRIME COATED
&
INSTALLED
WITH A
GREASE FITTING
MODEL #
GU-40
(SOLD EA.)
Rated to 1000 lbs per pair
(FLAT MOUNT BOTH SIDES)
PRIME COATED
MODEL #
GU-20
(SOLD EA.)
Rated to 3000 lbs per pair
(FLAT MOUNT BOTH SIDES)
HEAVY DUTY,STANDARD & GORILLA HINGES
HINGE
YOKE
“IT’S WHAT’S INSIDE THAT
MAKES THE DIFFERENCE
Hardened Steel
Inner Race
Grade 5
Zinc-Plated
Bolt
Retainer
Hardened Steel
Roller Cage
Bearing
Retainer
Zinc-Plated
Jamb Nut
H
inge
B
ody
G
rease
F
itting
S
tainless
S
teel
W
asher
S
tainless
S
teel
W
asher
grease
zerk
channel
york
INSTALLATION:GUARDIAN
gare hinges are
to
be mounted with
the york welded
to
the gate and
the
channel welded
to
the
post
,T
he hinges must
be
installed with
the hinge
pins
in
a
straight
line
.W
eld only on
the vertical
portions of
the yoke and
plate
.DO NOT
weld
the
top and
bottom of
the hinges
.MAINTENANCE:T
his
guardian gate hinge is equipped
with a grease zerk for easy lubrication.One pump of a high guality,multi purpose grease every 3 months should be sufficient under normal operating conditions.More frequent maintenance
is necessary under severe operating conditions.Do not over lubricate.
R
ound
M
ount
B
oth
S
ides
F
lat
M
ount
B
oth
S
ides
PRIME COATED
MODEL #
GU-25R
(SOLD EA.)
Rated to 3000 lbs per pair
(ROUND MOUNT BOTH SIDES)
MODEL #
GU-35R
(SOLD EA.)
Rated to 1000 lbs per pair
(ROUND MOUNT BOTH SIDES)
MODEL #
GU-21ALUM
(SOLD EA.)
Rated to 600 lbs per pair
(FLAT MOUNT BOTH SIDES)
MODEL #
GU-22ALUM
(SOLD EA.)
Rated to 600 lbs per pair
(FLAT & ROUND MOUNT)
ALUMINUM
BOTH SIDES
ALUMINUM &
STEEL
STEEL
ROUND MOUNT
TO POST
PRIME
COATED
MODEL #
GU-23STAIN
(SOLD EA.)
Rated to 1000 lbs per pair
(FLAT MOUNT BOTH SIDES)
STAINLESS
STEEL
STAINLESS STEEL
BOTH SIDES
STEEL
STEEL
PRIME COATED
MODEL #
GU-64R
(SOLD EA.)
Rated to 1000 lbs per pair
(ROUND MOUNT BOTH SIDES)
PLATE
YOKE
FIG.1
ALLOWS 180 DEGREE SWING
ALUMINUM
FLAT MOUNT
TO GATE
PRIME COATED
MODEL #
GU-60
(SOLD EA.)
Rated to 1000 lbs per pair
(FLAT MOUNT BOTH SIDES)
PRIME COATED
MODEL #
GU-90
(SOLD EA.)
Rated to 3000 lbs per pair
(FLAT MOUNT BOTH SIDES)
MADE IN THE USA
MADE IN THE USA
MADE IN THE USA
MADE IN THE USA
2 7/8”
3 9/16”
3 9/16”
2 7/8”
3 1/2”
2 7/8”
3 1/2”
2 7/8”
3 1/2”
3 1/8”
STEEL
