LOK-BOLTS WITH (HEX HEADS)
(DRILL SAME SIZE HOLE IN CONCRETE OR BRICK & TIGHTEN HEX NUT)
LOK-BOLTS,LAG BOLTS,SELF TAPPING,SHEET METAL SCREWS,GRINDING & CUT-OFF WHEELS
Model Size Drill Hole
Number Size
5100T.......... 5/16" x 1 1/2"..... 5/16"
5120T.......... 5/16 "x 2 1/2"..... 5/16"
5140T.......... 3/8" x 1 7/8"..... 3/8"
5160T.......... 3/8" x 3"........... 3/8"
5200T.......... 1/2" x 3"............. 1/2"
5240T.......... 1/2" x 4"............. 1/2"
Model Size Length
Number
3535............ 5/16". .......... Short
3537............ 5/16 ". ......... Long
3539............ 3/8" . ........... Short
3541............ 3/8" . .......... Long
Lead Shield
Model Size Style of color Type of
Number Screw Head
OPA-100........#10 x 1”.........Self Tapping........ Black................ Phillips
1PW-100........#10 x 1”.........Self Tapping........WHITE............. Phillips
20PA-100.......#12 x 1”.........Self Tapping........ BLACK............ Phillips
6900...............#8 x 1"...........Self Tapping........ Black................ 1/4" Hex
6810...............#10 x 1"......... Self Tapping....... Zinc Plated....... 5/16" Hex
6814...............#14 x 2" ........Self Tapping........ Zinc Plated....... 3/8" Hex
6930...............#8 x 1" .........Sheet Metal.......... Black................ Pan
6300...............1/4" x 1".........Lag Bolt............... Zinc Plated....... Hex
6420...............5/16" x 3" ......Lag Bolt............... Zinc Plated....... Hex
6500...............3/8" x 2' ........Lag Bolt............... Zinc Plated....... Hex
6520...............3/8" x 3" ........Lag Bolt............... Zinc Plated....... Hex
6540...............3/8" x 4" ........Lag Bolt............... Zinc Plated....... Hex
# 6900 & #6810
WORK WELLWITH
# 6100
SCREEN &
GLASS CLIPS
(Grinding Wheels)
Model Size hole
Number
M41405.........4"x1/4............ 5/8"
M41457.........4 1/2"x1/4"....7/8 "
M41707.........7"x1/4"...........5/8" WITH HUB
Model Diameter Hole
Number & Thickness Size
71701.............4" x 1/16"..............5/8"
M31079.........7"x1/8"..................5/8"
M31109..........10"x1/8"................1"
M31129..........12"x1/8"................1"
M31149..........14"x1/8"................1"
M31164..........16"x1/8"................1"
Quality
Cut-Off
Wheels
# OPA-100 & 1PW-100
410 STAINLESS STEEL
AVAIBLE IN BLACK OR
WHITE
SOLD IN BAGS
PER 100
*It is recommended to pre-drill hole when fixing to steel
