Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
STEEL & ALUMINUM SQUARE & RECTANGULAR BLOCK HINGES
SQUARE HINGES
TYPE OF
MODEL
HEIGHT SQ.
WEIGHT
STAINLESS CLEARENCE
MATERIAL
NUMBER
SIZE
SIZE
CAPACITY
STEEL PIN BETWEEN
PER/PAIR
SIZE
GATE & POST
STEEL- ----------------------# BLCS4-------4”- ------- 1”- -------------- 400 LBS---------1/2”------------1 1/4”
ALUMINUM- --------------# BLAS4-------4”- ------- 1”- -------------- 200 LBS---------1/2”------------1 1/4”
STEEL- ----------------------# BLCS6-------6”- ------- 1 1/2”----------- 600 LBS---------5/8”------------2”
ALUMINUM- --------------# BLAS6-------6”- ------- 1 1/2”----------- 300 LBS---------5/8”------------2”
STEEL- ----------------------# BLCS8-------8”- ------- 2”- -------------- 1200 LBS- ------3/4”------------2 1/2”
NOTE:BLCS6 & BLCS8 THE GREASE FITTING ARE MOUNTED ON THE SIDE
RECTANGULAR HINGES
TYPE OF
MODEL
HEIGHT RECT.
WEIGHT
STAINLESS CLEARENCE
MATERIAL
NUMBER
SIZE
SIZE
CAPACITY
STEEL PIN BETWEEN
PER/PAIR
SIZE
GATE & POST
STEEL- ----------------------# BLCS5------ 5”--------- 1”x1 1/4”- ----- 600 LBS-------- 5/8”- -----------1 1/2”
ALUMINUM- --------------# BLAS5------ 5”--------- 1”x1 1/4”- ----- 250 LBS-------- 5/8”- -----------1 1/2”
ALUMINUM & STEEL---# BLACS5---- 5”--------- 1”x1 1/4”- ----- 250 LBS-------- 5/8”- -----------1 1/2”
STEEL- ----------------------# BLCS7------ 7”--------- 1 1/4”x1 3/4”-- 800 LBS-------- 3/4”- -----------2 1/4”
ALUMINUM- --------------# BLAS7------ 7”--------- 1 1/4”x1 3/4”-- 400 LBS-------- 3/4”- -----------2 1/4”
ALUMINUM & STEEL---# BLACS7---- 7”--------- 1 1/4”x1 3/4”-- 400 LBS-------- 3/4”- -----------2 1/4”
SQUARE HINGES
RECTANGULAR
HINGES
*STEEL BLOCK HINGES
*ALUMINUM BLOCK HINGES
*ALUMINUM & STEEL BLOCK HINGES
(1/2 OF THE HINGE IS STEEL & THE OTHER 1/2 OF THE HINGE IS ALUMINUM)
EXAMPLE: IF YOU HAVE A STEEL POST & ALUMINUM GATE
(MADE IN THE U,S,A,)
SOLD IN PAIRS ONLY
