SURECLOSE POST MOUNTING BRACKETS FOR FLUSH AND CENTER MOUNT MODELS
MODEL # 7511 MODEL # 7512
MODEL # 7513 MODEL # 7514
MODEL # 7515D
MODEL # 7525 MODEL # 7526
CODE MODEL GAP VARIANCE 0 - -MOUNT MAX GATE FENCE POST HORIZONTAL
MODEL # FEATURE MATERIAL 0 - -TYPE SWING SIZE ADJUSTMENT
DESCRIPTION 0 - - DEGREE MINIMUM
7511------------------------------- ALUMINUM-----------------------------------------2 1/2”-3” (64MM-76MM)- ------ CENTER-------90---------------- 2 1/2”---------- YES
7512------------------------------- ALUMINUM-----------------------------------------2 1/2”-3” (64MM-76MM)- ------ CENTER-------90---------------- 2 1/2”---------- YES
7513------------------------------- ALUMINUM-----------------------------------------2 1/2”-3” (64MM-76MM)- ------ CENTER-------90---------------- 4”--------------- YES
7514-----------------ALUMINUM WITH SIDE FIXING CLAMP- ---------------2 1/2” (64MM) -------------------- CENTER-------90---------------- 2 1/2”---------- NO
7515D----------------------------- ALUMINUM-----------------------------------------1/2”(13MM) - -------------------- FLUSH---------180- ------------- 2”--------------- NO
7525------------------------------- STEEL-------------------------------------------------1/2”(13MM) - -------------------- FLUSH---------180- ------------- 2”--------------- NO
7526------------------------------- STEEL-------------------------------------------------2 1/2”-3” (64MM-76MM)- ------ CENTER-------90---------------- 2 1/2”---------- YES
